凯斯零件查询(110) - CASE IH QUADROBALE BALER (1/96-12/98) (109) - BALE STACKER, UPPER FLAP CONTROL (VAR.9045) Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
139 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
8308401
|
[1] |
LEVER
|
R
Shift lever
|
| 2. |
932335R1
|
[6] |
COTTER PIN,3.5mm OD x 36mm L, Slotted
|
IH
Tensioning pin 3,5x 36a
|
| 3. |
02356652
|
[6] |
SPLIT PIN/SAFETY PIN
|
R
Tensioning pin
|
| 4. |
8308423
|
[1] |
SHAFT
|
R
Control shaft
|
| 5. |
6321330
|
[4] |
BOLT (SPREADER)
|
R
Pin B10a12x 28
|
| 6. |
6321270
|
[4] |
FORK TEDDER
|
R
Fork head G10x40
|
| 7. |
100016
|
[4] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| 8. |
8308451
|
[2] |
ROD
|
R
Pull rod
|
| 9. |
8308431
|
[1] |
LEVER
|
R
Shift lever
|
| 10. |
6496940
|
[6] |
CYLINDER END CAP
|
R
Bearing
|
| 11. |
614-6020
|
[18] |
BOLT,Hex, M6 x 1 x 20mm, Cl 8.8, Full Thd
|
CAS
Superseded by part number: 120100
|
| . . |
825-1406
|
[18] |
NUT,M6, Cl 8
|
CAS
Superseded by part number: 86500688
|
| . . |
2393860
|
[18] |
WASHER
|
R
Contact washer Ers.d.2393860 Superseded by part number: 86588450
|
| 12. |
732-5032
|
[4] |
COTTER PIN,M5 x 32
|
CAS
Split pin 5 x 32
|
| 13. |
2342950
|
[4] |
WASHER
|
R
2 mm
|
| . . |
2342340
|
[1] |
WASHER
|
R
1 mm
|
| 14. |
732-4025
|
[4] |
COTTER PIN,M4 x 25
|
CAS
Split pin 4 x 22
|
| 15. |
2382920
|
[4] |
WASHER
|
R
|
| 16. |
2369420
|
[6] |
LUBE NIPPLE,M6 x 1
|
R
Grease nipple As 6x1 Superseded by part number: 321204
|
| 17. |
8308472
|
[2] |
PIN
|
R
Axle
|
| 18. |
8308463
|
[2] |
HOOK
|
R
|
| 19. |
9308870
|
[4] |
SPRING
|
R
Tension spring
|
| 20. |
0085140
|
[2] |
SPACER
|
R
Bushing
|
| 21. |
8309240
|
[1] |
HOOK
|
R
r.h. rechte Seite
|
| . . |
8309230
|
[1] |
HOOK
|
R
l.h. linke Seite
|
| 22. |
614-8070
|
[2] |
BOLT,Hex, M8 x 1.25 x 70mm, Cl 8.8, Full Thd
|
CAS
Hexagonal screw M 8x 70 Superseded by part number: 412108
|
| 23. |
43362
|
[4] |
NUT,M8 x 1.25, Cl 10
|
BHB
M8, Cl 10
|
| 24. |
2381320
|
[2] |
NUT
|
R
Securing nut Vm 8 Superseded by part number: 86528579
|
| 25. |
8309251
|
[2] |
LARGE PLATE
|
R
Coupler
|
