凯斯零件查询(110) - CASE IH QUADROBALE BALER (1/96-12/98) (110) - BALE STACKER, LOWER FLAP CONTROL (VAR.9045) Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
992 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
8308412
|
[1] |
LEVER
|
R
Shift lever
|
| 2. |
932335R1
|
[6] |
COTTER PIN,3.5mm OD x 36mm L, Slotted
|
IH
Tensioning pin 3,5x 36a
|
| 3. |
02356652
|
[6] |
SPLIT PIN/SAFETY PIN
|
R
Tensioning pin
|
| 4. |
8308423
|
[1] |
SHAFT
|
R
Control shaft
|
| 5. |
6321330
|
[4] |
BOLT (SPREADER)
|
R
Pin B10a12x 28
|
| 6. |
6321270
|
[4] |
FORK TEDDER
|
R
Fork head G10x40
|
| 7. |
100016
|
[4] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| 8. |
8308431
|
[3] |
LEVER
|
R
Shift lever
|
| 9. |
6496940
|
[2] |
CYLINDER END CAP
|
R
Bearing
|
| 10. |
2369420
|
[2] |
LUBE NIPPLE,M6 x 1
|
R
Grease nipple As 6x1 Superseded by part number: 321204
|
| 11. |
614-6020
|
[6] |
BOLT,Hex, M6 x 1 x 20mm, Cl 8.8, Full Thd
|
CAS
Superseded by part number: 120100
|
| . . |
825-1406
|
[6] |
NUT,M6, Cl 8
|
CAS
Superseded by part number: 86500688
|
| . . |
2393860
|
[6] |
WASHER
|
R
Contact washer Ers.d.2393860 Superseded by part number: 86588450
|
| 12. |
732-5032
|
[2] |
COTTER PIN,M5 x 32
|
CAS
Split pin 5 x 32
|
| 13. |
2342950
|
[4] |
WASHER
|
R
2 mm
|
| . . |
2342340
|
[1] |
WASHER
|
R
1 mm
|
| 14. |
732-4025
|
[4] |
COTTER PIN,M4 x 25
|
CAS
Split pin 4 x 22
|
| 15. |
2382920
|
[4] |
WASHER
|
R
|
| 16. |
8308441
|
[2] |
ROD
|
R
Pull rod
|
| 17. |
2445761
|
[2] |
SPLIT PIN/SAFETY PIN
|
R
Tensioning pin
|
| 18. |
8308492
|
[2] |
PAWL
|
R
|
| 19. |
9308870
|
[2] |
SPRING
|
R
Tension spring
|
| 22. |
8308502
|
[2] |
LARGE PIN
|
R
Ratched shaft
|
