| 1. |
667706R1
|
[1] |
|
P
ARM, pickup cover
|
| . . |
18508R1
|
[2] |
CARRIAGE BOLT,Short Nk, 3/8" - 16 x 3/4", Gr 2, Full Thd
|
IH
BOLT, 3/8 x 3/4 CDP sq-nk crg Superseded by part number: 86508748
|
| . . |
120377
|
[2] |
NUT,3/8" - 16, Gr 5
|
IH
Superseded by part number: 280136
|
| . . |
103321
|
[2] |
LOCK WASHER,3/8"
|
IH
WASHER, LOCK, 3/8" Superseded by part number: 80680
|
| . . |
187988
|
[1] |
COTTER PIN,3/16" x 1 1/4"
|
IH
PIN, SPLIT (COTTER), 3/16" x 1 1/4" Superseded by part number: 87398
|
| . . |
668752R1
|
[2] |
WASHER
|
IH
29/32 x 1-1/4 x 16 ga CDP (or as required) Superseded by part number: 86624165
|
| 2. |
667708R1
|
[1] |
|
P
BRACKET, pickup cover finger
|
| . . |
15054R1
|
[2] |
CARRIAGE BOLT,Short Sq Nk, 3/8" - 16 x 1 3/4", Gr 2
|
IH
BOLT, CARRIAGE, Short NK, 3/8"-16 x 1 3/4", G2 Superseded by part number: 111-381
|
| . . |
102635
|
[2] |
NUT,3/8"-16, G5
|
IH
Superseded by part number: 280136
|
| 3. |
662394R1
|
[6] |
FINGER
|
IH
TINE, pickup cover
|
| 4. |
668038R1
|
[1] |
|
P
ARM, pickup cover spring
|
| . . |
17411R1
|
[2] |
BOLT,Hex, 5/16"-18 X 3/4", G2
|
IH
5/16 x 3/4 hex-hd mach Superseded by part number: 179816
|
| . . |
103320
|
[2] |
LOCK WASHER,5/16"
|
IH
WASHER, LOCK, 5/16" Superseded by part number: 322358, 83990583
|
| . . |
9635082
|
[2] |
NUT,5/16" - 18, Gr 5
|
NH
5/16-18 hex.
|
| 5. |
662434R1
|
[1] |
|
P
CAM, pickup cover adjusting
|
| . . |
86508749
|
[1] |
CARRIAGE BOLT,Short Square Neck, 3/8" - 16 x 1 1/4", Grade 5
|
GI
BOLT, 3/8 x 1-1/4 sq-nk crg
|
| 6. |
521816R1
|
[1] |
SPRING
|
IH
pickup cover
|
