| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 009. | 8972142341 | [2] | STUD; CLIP | |
| 016. | 8980116060 | [1] | PIPE; INJ NO.1 | |
| 017. | 8980116070 | [1] | PIPE; INJ NO.2 | |
| 017. | 8980436840 | [1] | PIPE; INJ NO.2 | |
| 018. | 8980116080 | [1] | PIPE; INJ NO.3 | |
| 019. | 8980116090 | [1] | PIPE; INJ NO.4 | |
| 029. | 8970194730 | [10] | CLIP; HOSE | ID=10.5 |
| 030(A). | 0018041300 | [1] | HOSE; RUBBER,FUEL LEAK | L=130 |
| 030(B). | 8973546520 | [3] | HOSE; RUBBER,FUEL LEAK | L=98 |
| 030(C). | 8973623062 | [1] | HOSE; RUBBER,FUEL LEAK | |
| 031. | 8980116044 | [4] | NOZZLE ASM; INJ | |
| 059. | 8980115282 | [4] | CLAMP; NOZZLE HOLDER | C |
| 059. | 8980925390 | [4] | CLAMP; NOZZLE HOLDER | |
| 066. | 8980771650 | [4] | GASKET; INJ NOZZLE | C ALSO INCLUDED IN GASKET SET(ENG. & HEAD) |
| 066. | 8981815400 | [4] | GASKET; INJ NOZZLE | ALSO INCLUDED IN GASKET SET(ENG. & HEAD) |
| 068. | 8972134810 | [4] | CLIP; INJ PIPE | |
| 110. | 0911801060 | [2] | NUT; CLIP | M6 FLANGE |
| 122. | 8973152860 | [4] | CLIP; LEAK OFF PIPE | |
| 137(A). | 8973152302 | [1] | PIPE ASM; LEAK OFF | C |
| 137(A). | 8981610620 | [1] | PIPE ASM; LEAK OFF | |
| 137(B). | 8973152312 | [3] | PIPE ASM; LEAK OFF | C |
| 137(B). | 8981610610 | [3] | PIPE ASM; LEAK OFF | |
| 137(C). | 8980365100 | [1] | PIPE ASM; LEAK OFF | |
| 137(D). | 8980387750 | [1] | PIPE ASM; LEAK OFF | |
| 166. | 9095661110 | [4] | GASKET; FUEL INJECTOR | ALSO INCLUDED IN GASKET SET(ENG. & HEAD) |
| 175. | 1096300830 | [2] | GASKET; EYE BOLT,OUTLET,FUEL FEED PUMP | |
| 199. | 8976022180 | [2] | GASKET; EYE BOLT | |
| 205. | 8980235810 | [1] | SENSOR; FUEL TEMP | |
| 210. | 8973889020 | [1] | PIPE; INJ,C/R | |
| 211. | 8980118882 | [1] | RAIL ASM; COMMON | |
| 216(A). | 8980430330 | [1] | BOLT; EYE | |
| 216(B). | 9881300880 | [1] | BOLT; EYE | |
| 219. | 1096235410 | [1] | GASKET | ID=49.7 ALSO INCLUDED IN GASKET SET(ENGINE) |
| 265. | 8980749550 | [1] | VALVE; FEED PUMP | |
| 279(A). | 8943929240 | [2] | CLIP; FUEL HOSE | ID=16 |
| 279(B). | 8973756380 | [2] | CLIP; FUEL HOSE | ID=11.5 |
| 280. | 0280508120 | [1] | BOLT; CLIP,FUEL HOSE | M8X12 FLANGE |
| 282. | 8980539120 | [1] | BRACKET; COMMON RAIL | A |
| 282. | 8980118901 | [1] | BRACKET; COMMON RAIL | |
| 283(A). | 0280508700 | [2] | BOLT; COMMON RAIL | M8X70 FLANGE |
| 283(B). | 8973545840 | [2] | BOLT; COMMON RAIL | M8X81 FLANGE |
| 313. | 8973721440 | [4] | BOLT; BRKT,INJ NOZZLE | |
| 315(A). | 8980387770 | [1] | PIPE; FUEL,SUCTION | |
| 315(A). | 5154112231 | [1] | PIPE; FUEL,SUCTION | |
| 315(B). | 8980387780 | [1] | PIPE; FUEL,SUCTION | |
| 329. | 9095661100 | [1] | GASKET; SENSOR,FUEL PUMP | |
| 347. | 8973832860 | [4] | PIN | A |
| 347. | 8981650350 | [4] | PIN | |
| 348(A). | 8980388890 | [1] | HOSE; FUEL | |
| 348(B). | 8980505200 | [1] | HOSE; FUEL | |
| 408. | 8973815555 | [1] | PUMP; ASM FUEL,SUPPLY | |
| 418. | 0911802080 | [2] | NUT; COVER | M8 FLANGE |
| 424. | 8981454840 | [1] | OVERHAUL KIT; SUPPLY PUMP | |
| 424. | 8981455010 | [1] | OVERHAUL KIT; SUPPLY PUMP | |
| 425(A). | 8980387760 | [1] | BRACKET; VALVE | |
| 425(B). | 8980843930 | [1] | BRACKET; VALVE | |
| 426. | 0286508250 | [2] | BOLT; BRACKET | M8X25 FLANGE |
| 427. | 1096300850 | [3] | GASKET; FUEL PIPE | ID=14.2 OD=19.2 ALSO INCLUDED IN GASKET SET(ENGINE) |
| 428. | 8980198940 | [1] | COVER; VACUUM PUMP HOLE | |
| 429. | 0956902710 | [1] | GASKET; COVER | ALSO INCLUDED IN GASKET SET(ENGINE) |
