| 1. |
109461
|
[1] |
LUBE NIPPLE,1/8"-27 x .66 lg
|
IH
NIPPLE, LUBE, , PTF 1/8"-27 x .66 lg Superseded by part number: 80710
|
| 2. |
495177R21
|
[1] |
BEARING ASSY,4.5" OD x 2.97"
|
IH
BEARING ASSY, Pitman front
|
| . . |
180190
|
[2] |
LOCK SCREW,Hex, 1/2" - 13 x 3", Gr 5
|
IH
SCREW, 1/2-13 x 3 C-Z hex-hd cap Superseded by part number: 179893
|
| . . |
120384
|
[2] |
WASHER,1/2"
|
IH
LOCK, 1/2" Superseded by part number: 116121
|
| . . |
474848R1
|
[2] |
LOCK NUT,1/2"-13, GB
|
IH
NUT, 1/2-13 cd-pltd hex. lock Superseded by part number: 231-4218
|
| 3. |
495278R2
|
[16] |
SHIM
|
IH
Pitman brg
|
| 4. |
670587R91
|
[1] |
PITMAN
|
IH
ASSY
|
| 5. |
664976R1
|
[2] |
BUSHING,31.8mm ID x 34.95mm OD x 44.7mm L
|
IH
Pitman rear
|
| 6. |
127743
|
[1] |
LUBE NIPPLE,65 Degree, 1/8" NPT x 1.20" lg
|
IH
FITTING, 1/8-27 PTF 65 deg angle lub Superseded by part number: 219-41
|
| 7. |
668358R91
|
[1] |
SUPPORT
|
IH
BLOCK ASSY, plunger Pitman
|
| 8. |
668359R1
|
[1] |
BLOCK
|
IH
Pitman
|
| . . |
673707R1
|
[4] |
CARRIAGE BOLT,Sht Sq Nk, 1/2" - 13 x 1 1/2", Gr 5
|
IH
BOLT, 1/2-13 x 1-1/2 sq-nk crg type 2
|
| 9. |
670582R1
|
[1] |
BAFFLE
|
IH
plunger RH
|
| . . |
16897R1
|
[4] |
CARRIAGE BOLT,Short Nk, 5/16" - 18 x 3/4", Gr 2, Full Thd
|
IH
BOLT, 5/16 x 3/4 C-Z sq-nk crg Superseded by part number: 412-512
|
| . . |
120376
|
[4] |
NUT,5/16"-18, G5
|
IH
Superseded by part number: 9635082
|
| . . |
80681
|
[4] |
LOCK NUT,5/16"
|
NH
WASHER, LOCK, 5/16" Superseded by part number: 83990583
|
| 10. |
670581R1
|
[1] |
BAFFLE
|
IH
plunger LH
|
| 11. |
668368R1
|
[8] |
SHIM
|
IH
lower plunger .0299, (or as required)
|
| 12. |
668367R1
|
[4] |
PAD
|
IH
wear lower
|
| . . |
180075
|
[8] |
BOLT,Hex, 5/16" - 18 x 5/8", Gr 5
|
IH
SCREW, 5/16-18 x 5/8 C-Z hex-hd cap Superseded by part number: 9627874
|
| 13. |
200628C1
|
[1] |
WOOD
|
IH
BLOCK, plunger upper right
|
| . . |
18474R1
|
[4] |
BOLT,Hex, 5/16" - 18 x 1", Gr 2
|
IH
5/16 x 1 C-Z hex-hd mach Superseded by part number: 424-516
|
| . . |
453838
|
[4] |
NUT
|
IH
5/16-18 C-Z tee type 6
|
| 14. |
668365R1
|
[4] |
SHIM,45.72mm OD x 0.76mm Thk
|
IH
upper plunger right, (or as required)
|
| 15. |
670574R1
|
[1] |
PLUNGER ASSY
|
|
| 16. |
670434R1
|
[1] |
KNIFE ASSY
|
IH
KNIFE, hay
|
| . . |
21538R1
|
[2] |
CARRIAGE BOLT,#3, 5/8" - 11 x 1 1/2", Gr 2
|
IH
BOLT, 5/8 x 1-1/2 C-Z No. 3 repair hd plow
|
| . . |
425-110
|
[2] |
5/8-18 C-Z hex.
|
|
| . . |
492-11062
|
[2] |
BEARING WASHER,5/8"
|
CAS
WASHER, LOCK, 5/8" Superseded by part number: 86729275
|
| 17. |
668375R1
|
[1] |
BLOCK
|
IH
plunger upper center
|
| . . |
18422R1
|
[2] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 1 3/4", Gr 2
|
IH
BOLT, 3/8 x 1-3/4 C-Z sq-nk crg Superseded by part number: 411-628
|
| . . |
120377
|
[2] |
NUT,3/8" - 16, Gr 5
|
IH
Superseded by part number: 280136
|
| . . |
120382
|
[2] |
LOCK WASHER,Helical Spring, 3/8"
|
IH
WASHER, LOCK, 3/8" Superseded by part number: 80680
|
| 18. |
667922R1
|
[1] |
BOLT,Eye, 5/8" - 11 x 4.69"
|
IH
plunger eye
|
| . . |
120378
|
[2] |
NUT,Hex, 1/2" - 13, Gr 5
|
IH
NUT, 1/2"-13, G5 Superseded by part number: 280431
|
| 19. |
667923R1
|
[1] |
SLIDE
|
IH
plunger
|
| . . |
413-1032
|
[1] |
BOLT,Hex, 5/8" - 11 x 2", Gr 5
|
CAS
SCREW, 5/8-11 x 2 C-Z hex-hd cap Superseded by part number: 86505999
|
| 20. |
667935R1
|
[2] |
ANGLE
|
IH
plunger guide
|
| 21. |
674003R1
|
[1] |
ANCHOR
|
IH
plunger stop cable
|
| . . |
113-206
|
[2] |
BOLT,Hex, 3/8" - 16 x 3/4", Gr 5, Full Thd
|
CAS
3/8 x 3/4 znd hex-hd cap Superseded by part number: 86500692
|
| 22. |
670595R91
|
[2] |
TERMINAL CONNECTOR
|
IH
CLAMP ASSY, plunger stop cable
|
| . . |
492-11025
|
[4] |
LOCK WASHER,1/4"
|
CAS
WASHER, LOCK, 1/4" Superseded by part number: 72187247, 80682
|
| . . |
21784R1
|
[4] |
WASHER
|
IH
17/64 x 1/2 x 16 ga C-Z Superseded by part number: 86624137
|
| 23. |
670594R1
|
[1] |
HOSE
|
IH
SHIELD, plunger stop cable
|
| 24. |
670591R1
|
[1] |
CABLE
|
IH
ROPE, wire
|
| 25. |
674061R1
|
[1] |
PIVOT
|
IH
ASSY, plunger stop
|
| . . |
18495R1
|
[1] |
BOLT,Hex, 3/8" - 16 x 1 1/4", Gr 2
|
IH
3/8 x 1-1/4 znp hex-hd mach Superseded by part number: 180124
|
| 26. |
17295R1
|
[1] |
FITTING, 1/4-27 NPTF 67-1/2 deg lub
|
|
| 27. |
670585R1
|
[1] |
RAIL
|
IH
RUNNER, plunger roller
|
| 28. |
674056R1
|
[1] |
BOLT,Eye, 1/2" - 13 x 2.70"
|
IH
EYEBOLT, plunger guide
|
| . . |
120238
|
[2] |
JAM NUT,Jam, 1/2"-13, G5
|
IH
1/2-13 znd hex. jam Superseded by part number: 329-148
|
| . . |
20869R1
|
[4] |
WASHER
|
IH
17/32 x 7/8 x 16 ga C-Z Superseded by part number: 86622500
|
| 29. |
670584R1
|
[1] |
ANGLE
|
IH
plunger guide
|
| . . |
21741R1
|
[3] |
WASHER
|
IH
13/32 x 7/8 x 11 ga C-Z Superseded by part number: 495-81133
|
| . . |
180126
|
[2] |
BOLT,Hex, 3/8" - 16 x 1 1/2", Gr 5
|
IH
SCREW, 3/8-16 x 1-1/2 C-Z hex-hd cap Superseded by part number: 113-209
|
| . . |
138382
|
[2] |
WASHER, 3/8 C-Z med lock
|
SHAFT
|
| 30. |
670980R1
|
[1] |
|
P
CLIP, plunger stop pin
|
| 31. |
655919R1
|
[1] |
SPRING
|
IH
plunger stop Superseded by part number: 292927A1
|
| . . |
23311R1
|
[1] |
PIN, 5/8 x 7/8 C-Z std hd
|
|
| . . |
87395
|
[1] |
COTTER PIN,1/8" OD x 1-1/4" OAL
|
NH
PIN, SPLIT (COTTER), 1/8" x 1-1/4"
|
| . . |
21796R1
|
[1] |
WASHER
|
IH
21/32 x 1 x 16 ga C-Z Superseded by part number: 495-81176
|
| 32. |
667952R1
|
[1] |
STOP
|
IH
plunger
|
| 33. |
670586R1
|
[1] |
BRACKET
|
IH
plunger guide angle
|
| . . |
19019R1
|
[2] |
CARRIAGE BOLT,#3, 3/8" - 16 x 1", Gr 2
|
IH
BOLT, 3/8 x 1 C-Z No. 3 plow Superseded by part number: 419-3616
|
| . . |
19020R1
|
[5] |
PLOW BOLT,#3, 3/8" - 16 x 1 1/4", Gr 2
|
IH
BOLT, 3/8 x 1-1/4 C-Z No. 3 plow Superseded by part number: 19031R1
|
| 34. |
667937R2
|
[1] |
STRIP
|
IH
FILLER, lower plunger thrust spacer Superseded by part number: 203017C1, 203015C1, 203016C1
|
| 35. |
670579R2
|
[1] |
BAR
|
IH
RUNNER, plunger
|
| . . |
19007R1
|
[4] |
PLOW BOLT,#3, 5/16" - 18 x 1", Gr 2
|
IH
BOLT, 5/16 x 1 C-Z No. 3 plow
|
| 36. |
664542R1
|
[1] |
SHIM
|
IH
plunger thrust spacer lower, (or as required)
|
| 37. |
667936R2
|
[1] |
SPACER
|
IH
lower plunger thrust Superseded by part number: 203017C1, 203016C1, 203015C1
|
| 38. |
200631C1
|
[1] |
RAIL
|
IH
RUNNER, plunger thrust
|
| 39. |
200633C1
|
[1] |
DEFLECTOR
|
IH
ASSY, hay Superseded by part number: 204736C1
|
| . . |
17351R1
|
[2] |
CARRIAGE BOLT,Short Sq Nk, 3/8" - 16 x 1", Gr 2
|
IH
BOLT, 3/8 x 1 znd sq-hd crg Superseded by part number: 88682
|
| . . |
619856R1
|
[2] |
WASHER
|
IH
13/32 x 1 x 16 ga C-Z Superseded by part number: 87613182
|
