凯斯零件查询(425) - INTERNATIONAL HARVESTER RECTANGULAR BALER (1/76-12/85) (A-06) - BALE TENSION, MANUAL Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
828 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
3102968R1
|
[1] |
CHANNEL
|
IH
ASSY, lower tension
|
| . . |
18508R1
|
[3] |
CARRIAGE BOLT,Short Nk, 3/8" - 16 x 3/4", Gr 2, Full Thd
|
IH
BOLT, 3/8 x 3/4 crg type 1 Superseded by part number: 86508748
|
| . . |
102635
|
[3] |
NUT,3/8"-16, G5
|
IH
Superseded by part number: 280136
|
| . . |
103321
|
[3] |
LOCK WASHER,3/8"
|
IH
WASHER, LOCK, 3/8" Superseded by part number: 80680
|
| . . |
495-21044
|
[2] |
WASHER,3/8"
|
CAS
(.438 x 1.000 x .064 pln) 3/8" Superseded by part number: 87779090, 80702
|
| 2. |
3102972R1
|
[1] |
CHANNEL
|
IH
upper tension
|
| 3. |
670680R1
|
[1] |
SPRING
|
IH
tension
|
| . . |
18700R1
|
[1] |
CARRIAGE BOLT,Sq Nk, 7/16" - 14 x 3", Gr 2
|
IH
BOLT, 7/16 x 3 crg type 1 Superseded by part number: 411-748
|
| . . |
120383
|
[1] |
LOCK WASHER,Helical Spring, 7/16"
|
IH
WASHER, LOCK, 7/16" Superseded by part number: 81547
|
| . . |
271501
|
[1] |
SOCKET
|
NNA
NUT, 7/16 type 5
|
| 4. |
670681R91
|
[2] |
SCREW
|
IH
ASSY, tension
|
| 5. |
671126R91
|
[2] |
SUPPORT
|
IH
ASSY, tension
|
| . . |
20485R1
|
[2] |
BOLT,Short NK, 7/16"-14 x 3/4", G5. Full Thd
|
IH
7/16 x 3/4 crg type 1
|
| . . |
473213R1
|
[2] |
LOCK NUT,7/16"-14, GB
|
IH
NUT, 7/16-14 hex lock Superseded by part number: 280980
|
