凯斯零件查询(425) - INTERNATIONAL HARVESTER RECTANGULAR BALER (1/76-12/85) (A-11) - PTO SHAFTS WITH CHAINS, REAR, FITTED WITH LIP SEAL JOURNAL UNITS Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
433 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . . |
754792R95
|
[1] |
SHAFT
|
IH
W/CHAIN, PTO, hardy spicer Superseded by part number: 3103811R91
|
| . . |
3102304R91
|
[1] |
SHAFT
|
IH
PTO and guard w/chain, tractor end, consists of items marked A
|
| . . |
3102301R91
|
[1] |
SHAFT
|
IH
PTO and guard w/chain, implement end, consists of items marked B
|
| 1. |
3102315R91
|
[1] |
SHAFT ASSY, tabular
|
|
| . . |
3102306R91
|
[1] |
GUARD
|
IH
ASSY, outer half w/chain, red, (A) Superseded by part number: 3102306R92
|
| . . |
3103278R91
|
[1] |
CHAIN (AG)
|
IH
CHAIN
|
| 3. |
3102314R92
|
[1] |
SHAFT ASSY, yoke, (B)
|
|
| . . |
3102303R91
|
[1] |
GUARD
|
IH
ASSY, inner half w/chain, red, (B) Superseded by part number: 3102306R92
|
| . . |
3101268R91
|
[1] |
CHAIN (AG)
|
IH
CHAIN Superseded by part number: 3103278R91
|
| 4. |
3100758R91
|
[1] |
PACKAGE
|
IH
lip seal, (B)
|
| . . |
740493R1
|
[1] |
RING
|
IH
retaining
|
| . . |
3100759R1
|
[1] |
GASKET
|
IH
lip seal journal
|
| . . |
3102296R91
|
[1] |
LUBE NIPPLE
|
IH
LUBRICATOR
|
| 5. |
754876R1
|
[1] |
YOKE
|
IH
flange, (B)
|
