凯斯零件查询(425) - INTERNATIONAL HARVESTER RECTANGULAR BALER (1/76-12/85) (A-12) - PTO DRIVE SHAFT, 26 IN. MINIMUM COMPRESSION FOR USE ON TRACTORS WITH 14 IN. STD DRAWBAR Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
346 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . . |
3103139R91
|
[1] |
SHAFT
|
IH
W/CHAINS, PTO, hardy spicer Superseded by part number: 3103790R91
|
| . . |
3103141R91
|
[1] |
SHAFT
|
IH
PTO and guard assy w/chain, outer half, consists items marked B
|
| . . |
3103151R91
|
[1] |
SHAFT
|
IH
PTO and guard assy w/chain, inner half, consists items marked A
|
| 1. |
3101183R91
|
[1] |
YOKE
|
IH
ASSY, quick release, (A) Superseded by part number: 3103960R91
|
| 2. |
3101184R1
|
[1] |
PIN
|
IH
(A)
|
| 3. |
3101185R1
|
[1] |
VALVE SPRING
|
IH
SPRING, (A)
|
| 4. |
3101186R1
|
[1] |
PIN
|
IH
tension, (A) Superseded by part number: 3101184R1
|
| 5. |
3100758R91
|
[1] |
PACKAGE
|
IH
(A)
|
| 6. |
3103153R91
|
[1] |
YOKE
|
IH
and inner tube assy, (A)
|
| 7. |
3103148R1
|
[1] |
PIN
|
IH
tension, (A)
|
| 8. |
3103156R1
|
[1] |
TUBE
|
IH
inner, (A)
|
| 9. |
3103155R1
|
[1] |
YOKE
|
IH
inner tube, (A)
|
| 10. |
3103158R1
|
[1] |
GUARD
|
IH
ASSY, inner half, (A)
|
| . . |
3101268R91
|
[1] |
CHAIN (AG)
|
IH
CHAIN ASSY Superseded by part number: 3103278R91
|
| 11. |
3103149R1
|
[1] |
GUARD
|
IH
ASSY, outer halft, (B)
|
| 12. |
3103143R91
|
[1] |
YOKE
|
IH
AND OUTER TUBE ASSY, (B)
|
| 13. |
3103145R1
|
[1] |
TUBE
|
IH
YOKE, outer tube
|
| 14. |
3103146R1
|
[1] |
TUBE
|
IH
outer, (B)
|
| 17. |
3103386R1
|
[1] |
YOKE
|
IH
FLANGE, yoke, (B)
|
