| 1. |
3101596R1
|
[1] |
SHIELD
|
IH
ASSY, packer
|
| . . |
670454R1
|
[3] |
NUT
|
IH
5/16-18 speed grip
|
| . . |
179816
|
[4] |
BOLT,Hex, 5/16" - 18 x 3/4", Gr 5
|
IH
Superseded by part number: 87872
|
| . . |
120393
|
[1] |
BEARING WASHER,5/16", SAE
|
IH
WASHER, .344 x .688 x .051 Superseded by part number: 28588R1
|
| . . |
103320
|
[4] |
LOCK WASHER,5/16"
|
IH
WASHER, LOCK, 5/16" Superseded by part number: 322358, 83990583
|
| 2. |
667698R1
|
[1] |
WASHER
|
IH
packer crank brg front
|
| . . |
220724
|
[1] |
BOLT,Hex Hd, Lock, 7/16"-14 x 1 1/4", G5
|
IH
BOLT, 7/16 x 1-1/4 lock type 5 Superseded by part number: 70427R1
|
| 3. |
667861R1
|
[2] |
BEARING CAP,2.8346" ID x 4.8125" OD x 0.375"
|
IH
bearing retainer
|
| . . |
550796R1
|
[3] |
CARRIAGE BOLT,3/8" - 16 x 1 1/4", Grade 5
|
IH
BOLT, 3/8 x 1-1/4 crg type 5 Superseded by part number: 86508749
|
| . . |
102635
|
[3] |
NUT,3/8"-16, G5
|
IH
Superseded by part number: 280136
|
| . . |
103321
|
[3] |
LOCK WASHER,3/8"
|
IH
WASHER, LOCK, 3/8" Superseded by part number: 80680
|
| 4. |
571588R92
|
[1] |
BALL BEARING,1.3755" ID x 72 mm OD x 1"
|
IH
ASSY, packer crank front Superseded by part number: 47066
|
| 5. |
667763R1
|
[1] |
STRAP
|
IH
packer bearing adjusting
|
| . . |
17351R1
|
[1] |
CARRIAGE BOLT,Short Sq Nk, 3/8" - 16 x 1", Gr 2
|
IH
BOLT, 3/8 x 1 crg type 1 Superseded by part number: 88682
|
| . . |
103319
|
[1] |
LOCK WASHER,1/4"
|
IH
WASHER, LOCK, 1/4" Superseded by part number: 92-11025
|
| 6. |
674115R1
|
[1] |
SUPPORT
|
IH
packer brg front
|
| . . |
18508R1
|
[5] |
CARRIAGE BOLT,Short Nk, 3/8" - 16 x 3/4", Gr 2, Full Thd
|
IH
BOLT, 3/8 x 3/4 crg type 1 Superseded by part number: 86508748
|
| 7. |
667725R1
|
[1] |
PLATE
|
IH
packer bearing front support
|
| 8. |
667724R1
|
[1] |
ANCHOR
|
IH
packer bearing support
|
| . . |
NLS
|
[1] |
NO LONGER SERVICED
|
BAS
|
