| 1. |
413-840
|
[1] |
BOLT,Hex, 1/2" - 13 x 2-1/2", Gr 5
|
CAS
1/2 x 2-1/2 hex hd Superseded by part number: 87972
|
| . . |
102637
|
[1] |
NUT,1/2"-13, G5
|
IH
Superseded by part number: 280431
|
| . . |
178373R1
|
[1] |
WASHER
|
IH
.531 x 1.000 x .056 Superseded by part number: 495-51053
|
| 2. |
667768R1
|
[1] |
GEAR
|
IH
packer drive upper
|
| 3. |
21794R1
|
[1] |
WASHER
|
IH
1-13/32 x 2 x 20 ga Superseded by part number: 495-81212
|
| 4. |
608085R1
|
[4] |
WASHER
|
IH
1-13/32 x 2 x 20 ga, (or as required) Superseded by part number: 495-81213
|
| 5. |
667698R1
|
[1] |
WASHER
|
IH
packer crank brg front
|
| 6. |
3103026R91
|
[1] |
CRANKSHAFT
|
IH
ASSY, packer
|
| 7. |
3103126R2
|
[1] |
FINGER
|
IH
ASSY, packer
|
| . . |
179895
|
[1] |
BOLT,Hex, 1/2" - 13 x 3 1/2", Gr 5
|
IH
1/2 x 3-1/2 pln type 5 Superseded by part number: 9637417
|
| . . |
120384
|
[1] |
WASHER,1/2"
|
IH
LOCK, 1/2" Superseded by part number: 116121
|
| 8. |
3103136R1
|
[1] |
PIVOT
|
IH
packer relief rod Superseded by part number: 3103136R2
|
| . . |
159716C1
|
[2] |
SPACER,3/4" Tube x 5/8"
|
IH
.532 x .750 x .562
|
| . . |
179883
|
[2] |
BOLT,Hex, 1/2" - 13 x 1 1/4", Gr 5
|
IH
Superseded by part number: 180175
|
| . . |
395-11053
|
[2] |
WASHER,0.53" ID x 1.06" OD x 0.1" Thk
|
CAS
.531 x 1.062 x .074 pln
|
| . . |
103398
|
[2] |
COTTER PIN,5/32" x 1 1/2"
|
IH
Pin, Split (Cotter), 5/32" x 1 1/2" Superseded by part number: 132-341
|
| 9. |
3103132R1
|
[1] |
ROD
|
IH
packer relief
|
| . . |
432-1620
|
[1] |
COTTER PIN,1/4" x 1 1/4"
|
CAS
Pin, Split (Cotter), 1/4" x 1 1/4" Superseded by part number: 87402
|
| . . |
23885K
|
[1] |
SPACER,3/4" Tube x 2 1/16"
|
IH
.532 x .750 x 2.062
|
| . . |
87716
|
[1] |
BOLT,1/4"-20 x 1-1/4", Cl 5
|
PA
|
| . . |
3119440R1
|
[1] |
LOCK NUT
|
IH
1/4 UNC lock
|
| 10. |
3103125R1
|
[4] |
BEARING HALF
|
IH
BEARING, packer finger
|
| . . |
180113
|
[4] |
SPRING
|
NNA
5/16 x 3 type 5 Superseded by part number: 413-548, 413-548, 84814911
|
| . . |
231-1445
|
[4] |
NUT,5/16"-18, GB
|
CAS
NUT, LOCK, 5/16"-18, GB Superseded by part number: 86050277
|
| . . |
619855R1
|
[8] |
WASHER
|
IH
.344 x .750 x .054 Superseded by part number: 86637953
|
| 11. |
662555R1
|
[2] |
BUSHING,8.46mm ID x 15.98mm OD x 12.83mm L
|
IH
shear bolt
|
| 12. |
181620
|
[1] |
SCREW,Hex, 5/16" - 24 x 2", Gr 5
|
IH
BOLT, 5/16-24 x 2 hex hd Superseded by part number: 414-532
|
| . . |
120368
|
[1] |
NUT,5/16"-24, G5
|
IH
Superseded by part number: 86629539
|
| . . |
80681
|
[1] |
LOCK NUT,5/16"
|
NH
WASHER, LOCK, 5/16" Superseded by part number: 83990583
|
| 13. |
3103033R91
|
[1] |
CRANKSHAFT
|
IH
ASSY, packer rear
|
| 14. |
3103036R1
|
[1] |
SPACER
|
IH
packer crank
|
| 15. |
3100389R1
|
[1] |
THRUST WASHER
|
IH
thrust
|
| 18. |
3102892R1
|
[1] |
GEAR
|
IH
knotter drive shaft
|
| 19. |
477242R1
|
[3] |
WASHER
|
IH
13/32 x 1 x 22 ga, (or as required)
|
| 20. |
Q1482
|
[1] |
KEY,5/16" Sq x 1", Par
|
IH
5/16 x 1 parallel
|
| 21. |
3012893R1
|
[1] |
WASHER, gear knotted drive
|
|
| 22. |
120382
|
[1] |
LOCK WASHER,Helical Spring, 3/8"
|
IH
WASHER, LOCK, 3/8" Superseded by part number: 80680
|
| 23. |
180122
|
[1] |
BOLT,Hex, 3/8" - 16 x 1", Gr 5
|
IH
3/8-16 hex hd Superseded by part number: 113-207
|
| 24. |
3103122R1
|
[1] |
SUPPORT
|
IH
ASSY, packer relief
|
| . . |
179837
|
[3] |
BOLT,Hex, 3/8" - 16 x 3/4", Gr 5
|
IH
Superseded by part number: 86500692
|
| . . |
17351R1
|
[3] |
CARRIAGE BOLT,Short Sq Nk, 3/8" - 16 x 1", Gr 2
|
IH
BOLT, 3/8 x 1 crg type 1 Superseded by part number: 88682
|
| . . |
102635
|
[6] |
NUT,3/8"-16, G5
|
IH
Superseded by part number: 280136
|
| . . |
103321
|
[6] |
LOCK WASHER,3/8"
|
IH
WASHER, LOCK, 3/8" Superseded by part number: 80680
|
