| 1. |
667743R1
|
[1] |
SHEET
|
IH
right front top
|
| . . |
670454R1
|
[1] |
NUT
|
IH
5/16-18 speed grip
|
| . . |
18508R1
|
[3] |
CARRIAGE BOLT,Short Nk, 3/8" - 16 x 3/4", Gr 2, Full Thd
|
IH
BOLT, 3/8 x 3/4 crg type 1 Superseded by part number: 86508748
|
| . . |
102635
|
[3] |
NUT,3/8"-16, G5
|
IH
Superseded by part number: 280136
|
| . . |
103321
|
[3] |
LOCK WASHER,3/8"
|
IH
WASHER, LOCK, 3/8" Superseded by part number: 80680
|
| 2. |
667745R1
|
[1] |
SHEET
|
IH
right center top
|
| . . |
160536
|
[3] |
SCREW,Cross Pan Hd, 1/4" - 20 x 5/8"
|
IH
Superseded by part number: 86511931
|
| . . |
109084
|
[3] |
NUT,1/4"-20, G5
|
IH
Superseded by part number: 7770
|
| . . |
103319
|
[3] |
LOCK WASHER,1/4"
|
IH
WASHER, LOCK, 1/4" Superseded by part number: 92-11025
|
| 3. |
3102952R1
|
[1] |
SHEET
|
IH
right rear top
|
| 4. |
3102974R1
|
[1] |
DEFLECTOR
|
IH
ASSY, packer
|
| 5. |
3101826R1
|
[1] |
STRAP
|
IH
feed opening support
|
| . . |
179843
|
[1] |
BOLT,Hex, 3/8" - 16 x 1 1/2", Gr 5
|
NNA
Superseded by part number: 413-624, 413-624, NLS
|
| 6. |
203185C1
|
[1] |
ANGLE
|
IH
GUIDE, feed opening knife
|
| . . |
NLS
|
[2] |
NO LONGER SERVICED
|
BAS
|
| . . |
619856R1
|
[2] |
WASHER
|
IH
.406 x 1.000 x .056 Superseded by part number: 87613182
|
| 7. |
672150R1
|
[1] |
DEFLECTOR
|
IH
feed opening
|
| . . |
18635R1
|
[2] |
BOLT,Short NK, 1/4"-20 x 3", G2
|
IH
1/4 x 3 crg type 1 Superseded by part number: 111-115
|
| . . |
21872R1
|
[2] |
WASHER
|
IH
.406 x .625 x .054 Superseded by part number: 495-81128
|
| 8. |
3102953R2
|
[1] |
CHANNEL
|
IH
ASSY, packer
|
| . . |
17351R1
|
[4] |
CARRIAGE BOLT,Short Sq Nk, 3/8" - 16 x 1", Gr 2
|
IH
BOLT, 3/8 x 1 crg type 1 Superseded by part number: 88682
|
| 9. |
3101821R2
|
[1] |
SHEET
|
IH
ASSY, feed opening
|
| . . |
326-512
|
[3] |
BOLT,Hex, 5/16" - 18 x 3/4", Gr 8
|
CAS
SCREW, 5/16 x 3/4 znd slt truss hd
|
| . . |
9635082
|
[3] |
NUT,5/16" - 18, Gr 5
|
NH
5/16 pln hex
|
| . . |
103320
|
[3] |
LOCK WASHER,5/16"
|
IH
WASHER, LOCK, 5/16" Superseded by part number: 322358, 83990583
|
| . . |
120697
|
[3] |
SCREW, 1/4 x 3/4 znp f/hds mach
|
|
| . . |
95-11028
|
[3] |
WASHER,1/4"
|
CAS
.281 x .625 x .051 pln
|
