纽荷兰零件查询(FD20) - CRAWLER DOZER (C1.08[001]) - BRAKE SERVO New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
270 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 542717. | 542717 | [2] | BOOT | LEC |
| 590872. | 590872 | [2] | HYD CONNECTOR | LECCONNECTION |
| 4957861. | 4957861 | [2] | PISTON | LEC |
| 4957862. | 4957862 | [2] | BALL SOCKET | LEC |
| 4957863. | 4957863 | [2] | KEY | LEC |
| 4957864. | 4957864 | [2] | RING | LECLOCKRING |
| 4958206. | 4958206 | [2] | SPACER | LEC |
| 4958207. | 4958207 | [2] | ROD | LEC |
| 4959519. | 4959519 | [2] | ROD | LEC |
| 14457080. | 14457080 | [2] | O-RING,0.103" Thk x 0.487" ID, -112, Cl 5, 75 Duro | LECSEAL Superseded by part number: 86637641 |
| 14463280. | 14463280 | [2] | O-RING,24.99mm ID x 3.53" Width | BHB-214, 70 Duro, .984" ID x .139" Thk Superseded by part number: 14463281 |
| 14464481. | 14464481 | [2] | O-RING,0.139" Thk x 1.984" ID, -226, Cl 7, 75 Duro | BASSEAL Superseded by part number: 217408 |
