纽荷兰零件查询(FD20) - CRAWLER DOZER (C1.08/1[001]) - BRAKE SERVO New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
222 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 10260160. | 4858606 | [2] | SEAL,10.2mm ID x 16mm OD x 1mm Thk | TTFGASKET |
| 11059075. | 11059075 | [2] | LOCKING RING | MKTLOCKRING Superseded by part number: 11059076 |
| 11065975. | 11065975 | [2] | LOCKING RING | MKTLOCKRING Superseded by part number: 11065976 |
| 11066275. | 11066275 | [2] | LOCKING RING | MKTLOCKRING Superseded by part number: 11066276 |
| 11903171. | 11903171 | [2] | PLUG | MOD Superseded by part number: 11903111 |
| 14456880. | 14456880 | [2] | O-RING,0.103" Thk x 0.362" ID, -110, Cl 5, 75 Duro | MKTSEAL Superseded by part number: 14456881 |
| 14457880. | 14457880 | [2] | O-RING,0.103" Thk x 0.987" ID, -120, Cl 5, 75 Duro | JES-120, 70 Duro, .987" ID x .103" Thk |
| 79012708. | 79012708 | [2] | PIN | LECCARRIER Superseded by part number: 79030525 |
| 79012710. | 79012710 | [2] | PIN | LEC Superseded by part number: 79030526 |
| 79012711. | 79012711 | [2] | SEAT/SLOT | LECSEAT Superseded by part number: 79030527 |
| 79012720. | 79012720 | [2] | SPRING | LEC Superseded by part number: 79030528 |
| 79012721. | 79012721 | [2] | SPRING | LEC Superseded by part number: 79030529 |
| 79012722. | 79012722 | [2] | SPRING | LEC |
| 79012723. | 79012723 | [2] | WASHER | LEC Superseded by part number: 79030530 |
| 79012724. | 79012724 | [2] | WASHER | LEC Superseded by part number: 79030531 |
| 79030525. | 79030525 | [2] | PIN | LECCARRIER |
| 79030526. | 79030526 | [2] | PIN | LEC |
| 79030527. | 79030527 | [2] | RING | LECSEAT |
| 79030528. | 79030528 | [2] | SPRING | LEC |
| 79030529. | 79030529 | [2] | SPRING | LEC |
| 79030530. | 79030530 | [2] | WASHER | LEC |
| 79030531. | 79030531 | [2] | BUSHING | LECWASHER |
| 79030532. | 79030532 | [2] | PIN | LEC |
