凯斯零件查询(425) - INTERNATIONAL HARVESTER RECTANGULAR BALER (1/76-12/85) (A-32) - TUCKER FINGERS, UP TO 1979 Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
937 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
3102864R1
|
[2] |
STUD
|
IH
|
| . . |
103384
|
[2] |
COTTER PIN,1/8" x 3/4"
|
IH
Pin, Split (Cotter), 1/8" x 3/4" Superseded by part number: 80755
|
| 2. |
3102852R1
|
[1] |
ROD
|
IH
ASSY, tucker finger
|
| . . |
103409
|
[2] |
PIN, SPLIT (COTTER),3/16" x 1 1/2"
|
IH
Superseded by part number: 20328R1
|
| . . |
Q3478
|
[4] |
WASHER
|
IH
.781 x 1.250 x .067 pln, (or as required) Superseded by part number: 495-81038
|
| 3. |
3102857R1
|
[1] |
SPRING
|
IH
tension
|
| 4. |
3102858R1
|
[1] |
SPACER
|
IH
ROLLER, pivot tucker finger
|
| . . |
20869R1
|
[1] |
WASHER
|
IH
.531 x .875 x .054 Superseded by part number: 86622500
|
| 5. |
3102859R1
|
[2] |
FINGER
|
IH
ASSY, tucker Superseded by part number: 3103816R91
|
| 6. |
3102862R1
|
[2] |
BUSHING
|
IH
|
| 7. |
3102863R1
|
[2] |
BOLT (SPREADER)
|
IH
BOLT
|
| . . |
95-11041
|
[2] |
WASHER,3/8"
|
CAS
.406 x .812 x .051 pln Superseded by part number: 87016
|
| . . |
102635
|
[2] |
NUT,3/8"-16, G5
|
IH
Superseded by part number: 280136
|
| 8. |
3102865R1
|
[2] |
ROD
|
IH
tucker finger
|
