凯斯零件查询(425) - INTERNATIONAL HARVESTER RECTANGULAR BALER (1/76-12/85) (A-33) - TUCKER FINGERS, 1980 AND SINCE Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
980 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
3102864R1
|
[2] |
STUD
|
IH
|
| . . |
103384
|
[2] |
COTTER PIN,1/8" x 3/4"
|
IH
Pin, Split (Cotter), 1/8" x 3/4" Superseded by part number: 80755
|
| 2. |
3102852R1
|
[1] |
ROD
|
IH
ASSY, tucker finger
|
| . . |
103409
|
[2] |
PIN, SPLIT (COTTER),3/16" x 1 1/2"
|
IH
Superseded by part number: 20328R1
|
| . . |
Q3478
|
[4] |
WASHER
|
IH
.781 x 1.250 x .067 pln, (or as required) Superseded by part number: 495-81038
|
| 3. |
3102857R1
|
[1] |
SPRING
|
IH
tension
|
| 4. |
3102858R1
|
[1] |
SPACER
|
IH
ROLLER, pivot tucker finger
|
| . . |
20869R1
|
[1] |
WASHER
|
IH
.531 x .875 x .054 Superseded by part number: 86622500
|
| 5. |
3103816R91
|
[2] |
PLATE
|
IH
FINGER ASSY, tucker
|
| 5. |
3102860R1
|
[2] |
FINGER
|
IH
|
| 6. |
3103818R1
|
[2] |
PIVOT
|
IH
|
| 7. |
3102865R1
|
[2] |
ROD
|
IH
tucker finger
|
| 8. |
3103817R1
|
[2] |
SUPPORT
|
IH
|
| . . |
9635082
|
[4] |
NUT,5/16" - 18, Gr 5
|
NH
5/16 pln hex
|
| . . |
103320
|
[4] |
LOCK WASHER,5/16"
|
IH
WASHER, LOCK, 5/16" Superseded by part number: 322358, 83990583
|
| . . |
120393
|
[4] |
BEARING WASHER,5/16", SAE
|
IH
WASHER, .344 x .688 x .051 Superseded by part number: 28588R1
|
| 9. |
3102861R1
|
[2] |
STUD
|
IH
|
| . . |
120392
|
[1] |
WASHER,1/4", SAE
|
IH
.281 x .625 x .051 Superseded by part number: 87361
|
