凯斯零件查询(425) - INTERNATIONAL HARVESTER RECTANGULAR BALER (1/76-12/85) (A-34) - KNOTTER SHAFT BRAKE Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
228 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
U13033
|
[2] |
SPRING
|
IH
knotter brake
|
| . . |
18770R1
|
[2] |
BOLT,Hex, 5/16"-18 x 2 3/4", G2
|
IH
5/16 x 2-3/4 type 1 Superseded by part number: 180112
|
| . . |
120376
|
[2] |
NUT,5/16"-18, G5
|
IH
Superseded by part number: 9635082
|
| . . |
120393
|
[2] |
BEARING WASHER,5/16", SAE
|
IH
WASHER, .344 x .688 x .051 Superseded by part number: 28588R1
|
| 2. |
3102911R1
|
[1] |
SUPPORT
|
IH
ASSY, knotter brake
|
| . . |
113-233
|
[3] |
BOLT,Hex, 3/8" - 16 x 1-3/4", Gr 5
|
CAS
Superseded by part number: 9706689
|
| . . |
180126
|
[1] |
BOLT,Hex, 3/8" - 16 x 1 1/2", Gr 5
|
IH
3/8 x 1-1/2 type 5 Superseded by part number: 113-209
|
| . . |
120377
|
[4] |
NUT,3/8" - 16, Gr 5
|
IH
Superseded by part number: 280136
|
| . . |
120382
|
[4] |
LOCK WASHER,Helical Spring, 3/8"
|
IH
WASHER, LOCK, 3/8" Superseded by part number: 80680
|
| 3. |
3101603R1
|
[1] |
BRAKE
|
IH
ASSY, knotter shaft RH
|
| 4. |
3102914R1
|
[1] |
DISC
|
IH
ASSY, knotter brake
|
| 5. |
3101602R1
|
[1] |
BRAKE
|
IH
ASSY, knotter shaft LH
|
