凯斯零件查询(425) - INTERNATIONAL HARVESTER RECTANGULAR BALER (1/76-12/85) (A-34[A]) - AUGER DRIVE CHAIN Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
193 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
466971R1
|
[1] |
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 2", Gr 5
|
IH
BOLT, 1/2-13 x 2 crg Superseded by part number: 280185
|
| 2. |
3102910R1
|
[1] |
SUPPORT
|
IH
auger chain tensioner
|
| 3. |
495-11053
|
[1] |
WASHER,1/2", SAE
|
CAS
.531 x 1.062 x .074 Superseded by part number: 87364, 72187259
|
| 4. |
3103013R2
|
[1] |
SPACER
|
IH
|
| 5. |
3103012R1
|
[1] |
PRESS
|
IH
BUSHING, sprocket
|
| 6. |
3103010R91
|
[1] |
DRIVE SPROCKET
|
IH
SPROCKET, w/bushing, tensioner auger drive chain
|
| 8. |
120378
|
[1] |
NUT,Hex, 1/2" - 13, Gr 5
|
IH
NUT, 1/2"-13, G5 Superseded by part number: 280431
|
| . . |
120384
|
[1] |
WASHER,1/2"
|
IH
LOCK, 1/2" Superseded by part number: 116121
|
| . . |
21782R1
|
[1] |
WASHER
|
IH
.656 x 1.500 x .054 Superseded by part number: 87613191
|
| 9. |
3103009R1
|
[1] |
SHIELD
|
IH
auger drive chain
|
| . . |
704445R1
|
[2] |
NUT
|
IH
1/4-20 spire speed Superseded by part number: 86521425
|
| . . |
440-12510
|
[2] |
SCREW,Cross Pan Hd, 1/4"-20 x 5/8"
|
CAS
1/4-20 x 5/8 slt truss hd Superseded by part number: 86511931
|
| 10. |
3103006R1
|
[1] |
DRIVE SPROCKET
|
IH
SPROCKET, auger drive
|
| . . |
137141
|
[1] |
AXLE PIN
|
IH
PIN, 1/16 x 5/8 cot Superseded by part number: 107761
|
