纽荷兰零件查询(FD20) - CRAWLER DOZER (D2.27/A[001]) - PUMP New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
936 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 5110478. | 5110478 | [2] | SEAL | MOD Superseded by part number: 5153836 |
| 5120484. | 5120484 | [4] | SCREW | MKT |
| 8273909. | 8273909 | [2] | O-RING,0.103" Thk x 1.862" ID, -134, Cl 5, 75 Duro | MOD Superseded by part number: 374545 |
| 8273911. | 8273911 | [1] | CIRCLIP | TTFLOCKRING |
| 8273912. | 8273912 | [4] | BUSHING | MKT Superseded by part number: 5120207 |
| 8273918. | 8273918 | [1] | KEY | TTFFEATHER KEY |
| 8273919. | 8273919 | [1] | NUT | TTF Superseded by part number: 8299236 |
| 8273920. | 8273920 | [1] | LOCK WASHER | TTFLOCKWASHER |
| 8273940. | 8273940 | [2] | SUPPORT | MOD Superseded by part number: 5130130 |
| 8274234. | 8274234 | [1] | GEAR | LECSET |
| 8280168. | 8280168 | [1] | SHIM,23mm ID x 28.3mm OD x 1mm Thk | TTF |
| 8280169. | 8280169 | [1] | FLANGE | MKT Superseded by part number: 5120206 |
| 8281201. | 8281201 | [2] | RUBBER RING | MODO-RING |
| 8281576. | 8281576 | [5] | SEAL KIT | MODSET |
| 8283478. | 8283478 | [1] | COVER | MOD Superseded by part number: 5120204 |
| 10284460. | 10284460 | [4] | WASHER,M10.2 x 16 x 1.5, Copper | IMOWASHER, SEALING, M10.2 x 16 x 1.5, Copper |
| 10516871. | 10516871 | [4] | LOCK WASHER,10.2mm ID x 17.7mm OD x 2.5mm Thk | HFILOCKWASHER Superseded by part number: 10571873 |
| 12164721. | 12164721 | [4] | NUT,M10 x 1.25, Cl 10 | TTF |
| 14460380. | 14460380 | [2] | O-RING,0.103" Thk x 2.55" ID, -145, Cl 5, 75 Duro | MKT Superseded by part number: 9672457 |
