纽荷兰零件查询(FD20) - CRAWLER DOZER (D2.29[001]) - DISTRIBUTOR VALVE New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
835 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 575874. | 575874 | [2] | SPRING | LEC |
| 575888. | 575888 | [2] | PIN | LEC |
| 581658. | 581658 | [3] | PLUG | MOD Superseded by part number: 5116017 |
| 581967. | 581967 | [3] | PLUG | LECUNION Superseded by part number: 10300511, 10296160, NLS |
| 587158. | 587158 | [2] | PLUG | LEC |
| 591112. | 591112 | [1] | COMPRESSION SPRING,Compression, 12mm OD x 80mm L | LEC |
| 591126. | 591126 | [2] | HYD CONNECTOR | LECBODY |
| 591247. | 591247 | [1] | PLUG | LEC |
| 595736. | 595736 | [2] | CLEVIS | LECROLLER |
| 595878. | 595878 | [1] | PLUG | LEC |
| 4953884. | 4953884 | [2] | SPACER | LEC |
| 10257460. | 10257460 | [6] | SEAL,M20.3 x 26 x 1.5 | MKTWASHER, SEALING, , Copper M20.3 x 26 x 1.5 Superseded by part number: 98429280 |
| 14157470. | 14157470 | [2] | LOCK PIN,M1.5 x 10, Slotted | MKTTAPER PIN |
| 14323911. | 14323911 | [2] | PLUG | TTF |
| 14324801. | 14324801 | [2] | PLUG | MKT Superseded by part number: 16997211 |
| 14324901. | 14324901 | [2] | PLUG | MOD |
| 14330260. | 2852057 | [3] | SEALING WASHER,M8 x 12 x 1 Thk | TOR |
| 14456980. | 14456980 | [7] | O-RING,10.77mm ID x 2.62mm | LEC Superseded by part number: 14456981 |
| 14457380. | 5135738 | [2] | O-RING,0.103" Thk x 0.674" ID, -115, 80 Duro | TTF-115, 70 Duro, .674" ID x .103" Thk |
| 20063000. | 20063000 | [3] | BALL,15.08mm OD | MKT |
| 20063390. | 20063390 | [2] | BALL,8.73mm OD | TTF |
| 76010291. | 76010291 | [1] | GASKET | LEC Superseded by part number: 76028161 |
| 79002904. | 79003686 | [1] | SPRING | LECBODY Superseded by part number: 79030538 |
| 79004433. | 79004433 | [2] | SPACER,6mm ID x 16mm OD x 5.8mm L | MODROLLER |
| 79007717. | 79007717 | [1] | GASKET | LEC Superseded by part number: 76028137 |
| 79012735. | 79012735 | [2] | ECCENTRIC | LEC |
| 79030538. | 79030538 | [2] | SPRING | LEC |
