纽荷兰零件查询(FD20) - CRAWLER DOZER (D2.29[002]) - DISTRIBUTOR VALVE New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
314 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 586166. | 586166 | [1] | PLUG | MOD |
| 587138. | 587138 | [2] | BUSHING,15.8mm ID x 20.8mm OD x 20mm L | LECBUSH |
| 587141. | 587141 | [1] | SPACER | LEC |
| 587142. | 587142 | [2] | PIN | LEC |
| 587155. | 587155 | [1] | LEVER | LEC |
| 591115. | 591115 | [1] | GASKET | BHB Superseded by part number: 76028138 |
| 591217. | 591217 | [1] | LEVER | LEC |
| 4951841. | 4951841 | [1] | COVER | LEC |
| 4972293. | 4972293 | [1] | WASHER | LEC |
| 4972430. | 4972430 | [1] | CARRIER | LEC |
| 4972431. | 4972431 | [1] | CUP | LEC |
| 4972432. | 4972432 | [1] | WASHER,8mm ID x 12.5mm OD x 0.3mm Thk | LEC |
| 4972433. | 4972433 | [1] | HYDRAULIC VALVE | LECVALVE Superseded by part number: 76013437 |
| 4976146. | 4976146 | [1] | SPRING | LEC |
| 10257460. | 10257460 | [1] | SEAL,M20.3 x 26 x 1.5 | MKTWASHER, SEALING, , Copper M20.3 x 26 x 1.5 Superseded by part number: 98429280 |
| 10262660. | 10262660 | [1] | COPPER WASHER,M6.2 x 12 x .5, Copper | MKTGASKET |
| 10516671. | 10516671 | [6] | LOCK WASHER | BHBLOCKWASHER Superseded by part number: 83990583 |
| 11057175. | 11057175 | [1] | LOCKING RING | MKTLOCKRING Superseded by part number: 11057176 |
| 12647001. | 12647001 | [1] | WASHER,M8 x 25 x 2.5 | FOR Superseded by part number: |
| 14457280. | 14457280 | [2] | O-RING,0.103" Thk x 0.612" ID, -114, Cl 5, 75 Duro | BHB-114, 70 Duro, .612" ID x .103" Thk Superseded by part number: 14457281 |
| 16043131. | 16043131 | [1] | BOLT,Hex, M8 x 1.25 x 14mm, Cl 10.9, Full Thd | LEC |
| 16043431. | 16043431 | [3] | SCREW,Hex, M8 x 1.25 x 20mm, Cl 10.9, Full Thd | BHB Superseded by part number: 16605534 |
| 16043931. | 16043931 | [2] | SCREW,Hex, M8 x 1.25 x 35mm, Cl 10.9, Full Thd | LEC Superseded by part number: 16043934 |
