| 1. |
669006R1
|
[1] |
BUSHING
|
IH
BEARING, pickup wheel, 2 used in gauge wheel w/1-1/8 bore
|
| 1. |
202248C1
|
[1] |
BUSHING
|
IH
BEARING, pickup wheel, 2 used in gauge wheel w/1-3/8 bore
|
| 2. |
669005R1
|
[1] |
TYRE/TIRE
|
IH
TIRE, pickup wheel semi-pneumatic
|
| 3. |
669004R91
|
[1] |
WHEEL
|
IH
ASSY, pickup Superseded by part number: ZA400214
|
| 4. |
125617
|
[1] |
LUBE NIPPLE,3/16" x .61 lg, Drive
|
IH
FITTING, .191 str drive type lub, used w/Ohio Rubber Co. & Geneva Wheel Co. only Superseded by part number: 219-13
|
| 4. |
20691R1
|
[1] |
FITTING,3/16" x .47" lg, Drive
|
IH
.191 str drive type lub, used w/Dico Co. Wheel only Superseded by part number: 219-411
|
| 5. |
669003R91
|
[1] |
WHEEL
|
IH
PICKUP, w/semi-pneumatic tire Superseded by part number: ZA400214
|
| 6. |
674175R1
|
[1] |
SUPPORT
|
IH
BRACKET ASSY, pickup wheel
|
| . . |
NLS
|
[1] |
NO LONGER SERVICED
|
BAS
13/16 x 1-1/2 x 10 ga C-Z
|
| . . |
18794R1
|
[2] |
BOLT,Hex, 7/16" - 14 x 1", Gr 2
|
IH
7/16-14 x 1 C-Z hex-hd mach Superseded by part number: 9706729
|
| . . |
120383
|
[2] |
LOCK WASHER,Helical Spring, 7/16"
|
IH
WASHER, LOCK, 7/16" Superseded by part number: 81547
|
| . . |
607891R1
|
[1] |
WASHER
|
IH
15/32 x 1 x 16 ga C-Z Superseded by part number: 495-81158
|
| . . |
178375R1
|
[2] |
WASHER
|
IH
25/32 x 1-1/4 x 16 ga C-Z, (or as required) Superseded by part number: 249100
|
| . . |
187988
|
[1] |
COTTER PIN,3/16" x 1 1/4"
|
IH
PIN, SPLIT (COTTER), 3/16" x 1 1/4" Superseded by part number: 87398
|
