| 1. |
665450R1
|
[1] |
SEAL
|
IH
SEAL, Pitman brg front oil, 4 for wire Balers Superseded by part number: 665728R1
|
| . . |
24814R1
|
[2] |
|
P
SCREW, 7/16-14 x 3-3/4 znd hex-hd dld cap
|
| . . |
425-127
|
[2] |
SLOTTED NUT,7/16"-14, G5
|
CAS
NUT, 7/16-14 C-Z slt hex.
|
| . . |
454490
|
[2] |
PIN
|
IH
3/32 x 1-1/2 znp cot. Superseded by part number: 132-32
|
| 2. |
109461
|
[1] |
LUBE NIPPLE,1/8"-27 x .66 lg
|
IH
NIPPLE, LUBE, , PTF 1/8"-27 x .66 lg Superseded by part number: 80710
|
| 3. |
665716R11
|
[1] |
BEARING ASSY
|
IH
ASSY, Pitman front, for wire Balers
|
| 4. |
664975R1
|
[1] |
BEARING LINER
|
IH
INSERT, Pitman brg front, 2 for wire Balers
|
| 5. |
495177R21
|
[1] |
BEARING ASSY,4.5" OD x 2.97"
|
IH
BEARING ASSY, Pitman front, for twine Balers
|
| . . |
180190
|
[2] |
LOCK SCREW,Hex, 1/2" - 13 x 3", Gr 5
|
IH
SCREW, 1/2-13 x 3 C-Z hex-hd cap Superseded by part number: 179893
|
| . . |
120384
|
[2] |
WASHER,1/2"
|
IH
LOCK, 1/2" Superseded by part number: 116121
|
| . . |
474848R1
|
[2] |
LOCK NUT,1/2"-13, GB
|
IH
NUT, 1/2-13 C-Z hex. lock Superseded by part number: 231-4218
|
| 6. |
495278R2
|
[16] |
SHIM
|
IH
Pitman brg, (or as required), for twine Balers
|
| . . |
179893
|
[1] |
BOLT,Hex, 1/2" - 13 x 3", Gr 5
|
IH
SCREW, 1/2-13 x 3 hex-hd cap Superseded by part number: 87339
|
| 7. |
667943R91
|
[1] |
PITMAN
|
IH
ASSY, for twine Balers
|
| 8. |
664976R1
|
[2] |
BUSHING,31.8mm ID x 34.95mm OD x 44.7mm L
|
IH
Pitman rear
|
| 9. |
127743
|
[1] |
LUBE NIPPLE,65 Degree, 1/8" NPT x 1.20" lg
|
IH
FITTING, 1/8-27 PTF 65 deg angle lub Superseded by part number: 219-41
|
| 10. |
665714R91
|
[1] |
TUBE,35.75" Length
|
IH
PITMAN ASSY, for wire Balers
|
| 11. |
668358R91
|
[1] |
SUPPORT
|
IH
BLOCK ASSY, plunger Pitman
|
| 12. |
668359R1
|
[1] |
BLOCK
|
IH
Pitman
|
| . . |
673707R1
|
[4] |
CARRIAGE BOLT,Sht Sq Nk, 1/2" - 13 x 1 1/2", Gr 5
|
IH
BOLT, 1/2 x 1-1/2 sq-nk crg type 2 material
|
| 13. |
668362R1
|
[1] |
STRIP
|
IH
SCRAPER, plunger front
|
| . . |
271723
|
[1] |
SNAP RING,Hex, 5/8" - 11 x 2", Gr 5
|
NNA
SCREW, 5/8-11 x 2 C-Z hex-hd cap Superseded by part number: 413-1032, 413-1032, NLS
|
| . . |
492-11062
|
[1] |
BEARING WASHER,5/8"
|
CAS
WASHER, LOCK, 5/8" Superseded by part number: 86729275
|
| . . |
608701R1
|
[1] |
WASHER
|
IH
21/32 x 1-1/4 x 16 ga C-Z Superseded by part number: 86624155
|
| . . |
21793R1
|
[2] |
WASHER
|
IH
21/32 x 1-1/4 x 7 ga C-Z Superseded by part number: 495-81179
|
| 14. |
667925R91
|
[6] |
ROLLER BEARING,0.628" ID x 2" OD x 15 mm
|
IH
ROLLER, plunger Superseded by part number: 47577176
|
| . . |
413-1032
|
[1] |
BOLT,Hex, 5/8" - 11 x 2", Gr 5
|
CAS
SCREW, 5/8-11 x 2 znd hex-hd cap Superseded by part number: 86505999
|
| . . |
178627
|
[1] |
LOCK WASHER,Ext-Int Tooth, 5/8"
|
CAS
WASHER, 5/8 C-Z int-ext-tooth Superseded by part number: 193-50
|
| . . |
23836R1
|
[1] |
WASHER
|
IH
21/32 x 1-3/8 x 11 ga C-Z Superseded by part number: 5122064
|
| 15. |
674052R11
|
[1] |
ROLLER
|
IH
MOUNT ASSY, roller LH
|
| 16. |
668367R1
|
[2] |
PAD
|
IH
wearing lower
|
| . . |
180075
|
[4] |
BOLT,Hex, 5/16" - 18 x 5/8", Gr 5
|
IH
SCREW, 5/16-18 x 5/8 C-Z hex-hd cap Superseded by part number: 9627874
|
| . . |
80681
|
[4] |
LOCK NUT,5/16"
|
NH
WASHER, LOCK, 5/16" Superseded by part number: 83990583
|
| 17. |
664542R1
|
[1] |
SHIM
|
IH
plunger thrust spacer lower, (or as required)
|
| . . |
425-110
|
[2] |
5/8-18 C-Z hex.
|
|
| 18. |
668368R1
|
[4] |
SHIM
|
IH
plunger lower, (or as required)
|
| 19. |
668365R1
|
[2] |
SHIM,45.72mm OD x 0.76mm Thk
|
IH
plunger upper right, (or as required)
|
| 20. |
668364R2
|
[1] |
BLOCK
|
IH
plunger upper right
|
| . . |
18474R1
|
[2] |
BOLT,Hex, 5/16" - 18 x 1", Gr 2
|
IH
5/16 x 1 C-Z hex-hd mach Superseded by part number: 424-516
|
| . . |
453838
|
[2] |
NUT
|
IH
5/16-18 C-Z tee type G
|
| 21. |
674043R2
|
[1] |
PLUNGER
|
IH
ASSY
|
| 22. |
667684R2
|
[1] |
KNIFE
|
IH
hay Superseded by part number: 203021C1
|
| . . |
21538R1
|
[3] |
CARRIAGE BOLT,#3, 5/8" - 11 x 1 1/2", Gr 2
|
IH
BOLT, 5/8 x 1-1/2 C-Z No. 3 plow repair hd
|
| . . |
121358
|
[3] |
YOKE
|
NNA
5/8-18 C-Z hex. Superseded by part number: 425-1110, 425-1110, NLS
|
| 23. |
668375R1
|
[1] |
BLOCK
|
IH
plunger upper center
|
| . . |
18422R1
|
[2] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 1 3/4", Gr 2
|
IH
BOLT, 3/8 x 1-3/4 C-Z sq-nk crg Superseded by part number: 411-628
|
| . . |
120377
|
[2] |
NUT,3/8" - 16, Gr 5
|
IH
Superseded by part number: 280136
|
| . . |
120382
|
[2] |
LOCK WASHER,Helical Spring, 3/8"
|
IH
WASHER, LOCK, 3/8" Superseded by part number: 80680
|
| 24. |
667922R1
|
[1] |
BOLT,Eye, 5/8" - 11 x 4.69"
|
IH
plunger eye
|
| . . |
120378
|
[2] |
NUT,Hex, 1/2" - 13, Gr 5
|
IH
NUT, 1/2"-13, G5 Superseded by part number: 280431
|
| 25. |
668363R1
|
[1] |
SCRAPER
|
IH
plunger rear
|
| . . |
12872R1
|
[1] |
BOLT,Short NK, 5/16"-18 x 1", G2, Full Thd
|
IH
CARRIAGE, Short NK, 5/16"-18 x 1", G2, Full Thd Superseded by part number: 598803R1
|
| . . |
120376
|
[1] |
NUT,5/16"-18, G5
|
IH
Superseded by part number: 9635082
|
| . . |
120393
|
[1] |
BEARING WASHER,5/16", SAE
|
IH
WASHER, 11/32 x 11/16 x 16 ga C-Z Superseded by part number: 28588R1
|
| 26. |
674053R1
|
[2] |
STUD
|
IH
roller mount LH
|
| 27. |
674057R1
|
[2] |
ANGLE
|
IH
plunger guide
|
| . . |
180118
|
[1] |
BOLT,Hex, 3/8" - 16 x 5/8", Gr 5
|
IH
SCREW, 3/8-16 x 5/8 C-Z hex-hd cap, 12 for twine Balers, 10 for wire Balers Superseded by part number: 88703
|
| . . |
113-206
|
[1] |
BOLT,Hex, 3/8" - 16 x 3/4", Gr 5, Full Thd
|
CAS
3/8-16 x 3/4 C-Z hex-hd cap, 2 for wire Balers Superseded by part number: 86500692
|
| . . |
138542
|
[1] |
LOCK WASHER,Int Tooth, 3/8"
|
IH
WASHER, LOCK, , 2 for wire balers Int Tooth, 3/8" Superseded by part number: 9672276
|
| . . |
477242R1
|
[6] |
WASHER
|
IH
13/32 x 1 x 22 ga C-Z
|
| 29. |
674056R1
|
[2] |
BOLT,Eye, 1/2" - 13 x 2.70"
|
IH
plunger guide eye
|
| . . |
120238
|
[2] |
JAM NUT,Jam, 1/2"-13, G5
|
IH
1/2-13 znp hex. jam Superseded by part number: 329-148
|
| . . |
21741R1
|
[1] |
WASHER
|
IH
13/32 x 7/8 x 11 ga C-Z, (or as required) Superseded by part number: 495-81133
|
| 30. |
201581C1
|
[1] |
STOP
|
IH
ARM ASSY, plunger stop, replaces 674066R1 and 674069R1
|
| . . |
20869R1
|
[1] |
WASHER
|
IH
17/32 x 7/8 x 16 ga C-Z Superseded by part number: 86622500
|
| . . |
18481R1
|
[1] |
COTTER PIN,3/16" x 1"
|
IH
PIN, SPLIT (COTTER), 3/16" x 1" Superseded by part number: 432-1216
|
| 31. |
674071R1
|
[1] |
BRACKET
|
IH
plunger stop mounting
|
| . . |
18508R1
|
[2] |
CARRIAGE BOLT,Short Nk, 3/8" - 16 x 3/4", Gr 2, Full Thd
|
IH
BOLT, 3/8 x 3/4 C-Z sq-nk crg Superseded by part number: 86508748
|
| 32. |
674072R1
|
[1] |
CLEVIS
|
IH
plunger stop link
|
| 33. |
674064R1
|
[1] |
LINKAGE
|
IH
LINK, plunger stop
|
| . . |
137185
|
[2] |
COTTER PIN,1/8" x 1"
|
IH
PIN, SPLIT (COTTER), 1/8" x 1" Superseded by part number: 80755
|
| . . |
21740R1
|
[2] |
WASHER
|
IH
17/32 x 1-1/2 x 16 ga C-Z Superseded by part number: 495-81161
|
| 34. |
674054R1
|
[1] |
BUSHING
|
IH
plunger roller mount
|
| 35. |
674058R21
|
[2] |
BEARING ASSY
|
IH
BEARING ASSY, plunger roller Superseded by part number: 47577176, 674058R2
|
| 36. |
655919R1
|
[1] |
SPRING
|
IH
plunger stop Superseded by part number: 292927A1
|
| 37. |
674065R1
|
[1] |
ANCHOR
|
IH
plunger stop spring
|
| 38. |
664301R1
|
[1] |
SPRING
|
IH
plunger stop relief
|
| 39. |
332040
|
[1] |
LUBE NIPPLE,90 Degree, 1/8" NPT x .84" lg
|
WIN
FITTING, 1/8-27 PTF 90 deg angle lub
|
| 40. |
674061R1
|
[1] |
PIVOT
|
IH
ASSY, plunger stop
|
| . . |
18495R1
|
[1] |
BOLT,Hex, 3/8" - 16 x 1 1/4", Gr 2
|
IH
3/8 x 1-1/4 C-Z hex-hd mach Superseded by part number: 180124
|
| 41. |
674060R1
|
[1] |
STOP
|
IH
plunger
|
| 42. |
203032C1
|
[1] |
ANGLE
|
IH
plunger guide thrust, replaces 674055R1
|
| . . |
19020R1
|
[4] |
PLOW BOLT,#3, 3/8" - 16 x 1 1/4", Gr 2
|
IH
BOLT, 3/8-16 x 1-1/4 znd No. 3 plow Superseded by part number: 19031R1
|
| . . |
19023R1
|
[2] |
CARRIAGE BOLT,#3, 3/8" - 16 x 2", Gr 2
|
IH
BOLT, 3/8-16 x 2 znd No. 3 plow Superseded by part number: 419-3632
|
| 43. |
674059R2
|
[1] |
LARGE PLATE
|
IH
EXTENSION, bottom plate
|
| 44. |
674073R1
|
[1] |
SLEEVE
|
IH
ASSY, plunger stop spring
|
| . . |
20704R1
|
[1] |
WASHER
|
IH
1-1/32 x 1-1/2 x 11 ga C-Z Superseded by part number: 86624170
|
| . . |
21648R1
|
[1] |
LOCK PIN,1/4" x 1 1/4", Slotted
|
IH
Pin, 1/4" x 1 1/4", Slotted Superseded by part number: 438-11620
|
| . . |
366112R1
|
[1] |
WASHER
|
IH
25/32 x 1-1/4 x 11 ga C-z Superseded by part number: 87024778
|
| . . |
22752R1
|
[1] |
SPLIT PIN/SAFETY PIN
|
IH
PIN, 3/8 x 2-1/4 znp std-hd Superseded by part number: 86624081
|
| . . |
648002
|
[1] |
1/8" x 3/4"
|
KNIFE
|
| . . |
619856R1
|
[1] |
WASHER
|
IH
13/32 x 1 x 16 ga C-Z Superseded by part number: 87613182
|
| 45. |
667936R2
|
[1] |
SPACER
|
IH
lower plunger thrust, 430T Balers 009785 and below, 430W Balers 001503 and below, 440T Balers 003569 and below, 440W Balers 002028 and below Superseded by part number: 203017C1, 203016C1, 203015C1
|
| 46. |
667937R2
|
[1] |
STRIP
|
IH
Superseded by part number: 203017C1, 203015C1, 203016C1
|
| 47. |
674582R1
|
[1] |
NIPPLE, LUBE
|
IH
NIPPLE, plunger stop
|
| 50. |
203015C1
|
[1] |
PLATE
|
IH
STRIP, plunger thrust, 430T Balers 009786 and up, 430W Balers 001504 and up, 440T Balers 003570 and up, 440W Balers 002029 and up Superseded by part number: 203015C2, 664542R1
|
| . . |
180077
|
[6] |
BOLT,Hex, 5/16" - 18 x 3/4", Gr 5
|
IH
SCREW, 5/16-18 x 3/4 znd hex-hd cap Superseded by part number: 87872
|
| . . |
9635884
|
[2] |
BOLT,Hex, 5/16" - 18 1", Full Thd, Gr 5
|
NH
5/16-18 x 1 znd hex-hd cap
|
| . . |
180080
|
[1] |
BOLT,Hex, 5/16" - 18 x 1 1/8", Gr 5, Full Thd
|
IH
SCREW, 5/16-18 x 1-1/8 znd hex-hd cap Superseded by part number: 413-518
|
| . . |
23060R1
|
[9] |
LOCK WASHER,Int Tooth, 5/16"
|
IH
WASHER, 5/16 znd int. tooth lock (440 Baler) Superseded by part number: 193-67
|
| . . |
22859R1
|
[9] |
WASHER
|
IH
11/32 x 3/4 x 7 ga C-Z Superseded by part number: 495-81113
|
