纽荷兰零件查询(FD255) - CRAWLER DOZER (N.A. VERSION) (7/95-) (0.060[01]) - CYLINDER HEAD New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
400 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 61319085 | [2] | CYLINDER HEAD GASKET,1.78mm Thk | LEC |
| 2. | 4815557 | [28] | SCREW | LEC16X1,5X172 |
| 6. | 61320064 | [2] | CYLINDER HEAD | ZED- ASSY Superseded by part number: 61321866 |
| 3. | 61315656 | [28] | WASHER | LEC |
| 4. | 61316199 | [1] | COVER | LEC |
| 5. | 61319394 | [2] | GASKET,1.6mm Thk | LEC |
| 7. | 61315368 | [3] | VALVE SEAT | LEC- INTAKE VALVE, Serial Range: -C3747 Superseded by part number: 500310810 |
| 7. | 61321083 | [3] | VALVE SEAT | ZED- INTAKE VALVE, Start Serial: D3747 Superseded by part number: 500310810 |
| 8. | 61315085 | [3] | VALVE SEAT | LEC- EXHAUST VALVE, Serial Range: -C3747 Superseded by part number: 500310811 |
| 8. | 61321082 | [3] | SEAT/SLOT | LEC- EXHAUST VALVE, Start Serial: D3747 Superseded by part number: 500310811 |
| 9. | 61584412 | [1] | PLUG | ZED Superseded by part number: 500376561 |
| 10. | 14326101 | [1] | PLUG | BAS8X1,25 |
| 11. | 61585072 | [6] | EXHAUST VALVE GUIDE | LEC |
| 11. | 61577137 | [6] | VALVE GUIDE | LEC- VALVE Superseded by part number: 61585072 |
| 11. | 61689487 | [6] | OVERSIZE INLET VALVE | LEC- VALVE +0,2 |
| 12. | 61315088 | [3] | SLEEVE | LEC- INJECTOR |
| 13. | 61582822 | [6] | O-RING | LEC |
| 14. | 13450634 | [12] | STUD | LEC10X1,25X1,5X75 |
| 15. | 11190574 | [12] | BELLEVILLE WASHER,Belleville, M10.5 | TTF |
| 16. | 12164721 | [12] | NUT,M10 x 1.25, Cl 10 | TTF |
| 17. | 4700162 | [12] | WASHER | BRE |
| 18. | 61316819 | [1] | COVER | LEC |
| 19. | 13543321 | [2] | STUD | TOR8X1,25X16X20 Superseded by part number: 16746624 |
| 20. | 11193874 | [2] | BELLEVILLE WASHER,8.4mm ID x 16.00mm OD x 1.4mm, 1.85mm, Cl 8.8 | TTF |
| 21. | 16100821 | [2] | NUT,M8, Cl 10 | LEC Superseded by part number: 43362 |
| 22. | 16045024 | [10] | BOLT,Hex, M8 x 1.25 x 90mm, Cl 8.8 | IMO |
| 24. | LEC1940141 | [1] | ENGINE TOP GASKETS KIT | LECSEE PAGE 32 |
| 24. | 1940142 | [1] | ENGINE GASKET KIT | LECSEE PAGE 32 |
| 25. | 14282470 | [9] | PLUG,M28, Tapered, Stainless | TOR Superseded by part number: 16990870 |
| 26. | 14282670 | [3] | PLUG,M32, Tapered, Stainless | MKT Superseded by part number: 16991070 |
| 22. | 16044321 | [12] | BOLT,M8 x 1.25 x 55mm, Cl 8.8 | NH |
