| 1. |
674180R1
|
[1] |
|
P
SUPPORT ASSY, twin can
|
| . . |
18508R1
|
[2] |
CARRIAGE BOLT,Short Nk, 3/8" - 16 x 3/4", Gr 2, Full Thd
|
IH
BOLT, 3/8 x 3/4 C-Z sq-nk crg Superseded by part number: 86508748
|
| . . |
17351R1
|
[2] |
CARRIAGE BOLT,Short Sq Nk, 3/8" - 16 x 1", Gr 2
|
IH
BOLT, 3/8 x 1 C-Z sq-nk crg Superseded by part number: 88682
|
| . . |
120377
|
[4] |
NUT,3/8" - 16, Gr 5
|
IH
Superseded by part number: 280136
|
| . . |
120382
|
[4] |
LOCK WASHER,Helical Spring, 3/8"
|
IH
WASHER, LOCK, 3/8" Superseded by part number: 80680
|
| 2. |
662371R91
|
[1] |
CAM
|
IH
CAN ASSY, twine
|
| . . |
16897R1
|
[5] |
CARRIAGE BOLT,Short Nk, 5/16" - 18 x 3/4", Gr 2, Full Thd
|
IH
BOLT, 5/16 x 3/4 C-Z sq-nk crg Superseded by part number: 412-512
|
| . . |
120376
|
[5] |
NUT,5/16"-18, G5
|
IH
Superseded by part number: 9635082
|
| . . |
80681
|
[5] |
LOCK NUT,5/16"
|
NH
WASHER, LOCK, 5/16" Superseded by part number: 83990583
|
| . . |
440-12510
|
[2] |
SCREW,Cross Pan Hd, 1/4"-20 x 5/8"
|
CAS
1/4-20 x 5/8 C-Z slt-truss-hd mach Superseded by part number: 86511931
|
| . . |
938016R1
|
[2] |
FLANGE NUT,Flg, USR, 1/4"-20
|
IH
1/4-20 znd hex lock Superseded by part number: 523282
|
| 3. |
662409R1
|
[1] |
ROD
|
IH
twine can door pivot
|
| 4. |
668035R11
|
[2] |
LATCH
|
IH
ASSY, twine can door
|
| . . |
15054R1
|
[2] |
CARRIAGE BOLT,Short Sq Nk, 3/8" - 16 x 1 3/4", Gr 2
|
IH
BOLT, CARRIAGE, Short NK, 3/8"-16 x 1 3/4", G2 Superseded by part number: 111-381
|
| 5. |
668036R1
|
[2] |
PAWL
|
IH
twine can fastener
|
| 6. |
354746R1
|
[2] |
SPRING
|
IH
twine can door fastener
|
| . . |
469668R1
|
[2] |
WASHER
|
IH
13/32 x 3/4 x 16 ga C-Z Superseded by part number: 86632580
|
| . . |
385525R1
|
[2] |
LOCK NUT,3/8"-16, GB
|
IH
NUT, 3/8-16 cad hex lock Superseded by part number: 87039402
|
| 7. |
662386R2
|
[1] |
DOOR
|
IH
twine can
|
| . . |
85700996
|
[2] |
SCREW,Phillips Drive, Pan HD, 1/4" - 20 x 1/2"
|
WIN
1/4-20 x 1/2 C-Z slt-truss-hd
|
| . . |
120375
|
[2] |
NUT,Hex, 1/4" - 20, Gr 5
|
IH
Superseded by part number: 7770
|
| . . |
21549
|
[2] |
TIP
|
SAS
WASHER, 9/32 x 3/4 x 18 ga C-Z Superseded by part number: 22534
|
| 8. |
662380R1
|
[1] |
GUIDE
|
IH
PLATE, twine tension
|
| 9. |
269920R2
|
[2] |
SPRING
|
IH
twine tension roller
|
| 10. |
832120
|
[2] |
WASHER, twine roller spring cup
|
|
| . . |
495058R2
|
[2] |
BOLT,Carriage, 1/4" - 20 x 3"
|
IH
1/4 x 3 C-Z sq-nk crg
|
| . . |
126177
|
[2] |
WING NUT
|
IH
NUT, 1/4-20 znd wing Superseded by part number: 129-409, 129-409, 86627130
|
| 11. |
670617R2
|
[1] |
GUIDE
|
IH
twine Superseded by part number: 3102165R2
|
| 12. |
352133R1
|
[1] |
PLATE
|
IH
twine guide mounting
|
| . . |
436730
|
[2] |
LOCK SCREW,Slotted Pan Hd, #10-24 x 3/8"
|
IH
SCREW, 10-24 x 3/8 znd slt-pan-hd mach Superseded by part number: 159908
|
| . . |
120217
|
[2] |
LOCK WASHER,#10
|
IH
WASHER, LOCK, #10 Superseded by part number: 80684
|
| . . |
120361
|
[2] |
NUT,Hex Mach Screw, #10 - 24
|
IH
Superseded by part number: 87304
|
| 13. |
673760R1
|
[1] |
PLATE
|
IH
twine tension outside
|
