| 1. |
674100R2
|
[1] |
SUPPORT
|
IH
knotter shaft brg Superseded by part number: 203040C1
|
| . . |
17351R1
|
[2] |
CARRIAGE BOLT,Short Sq Nk, 3/8" - 16 x 1", Gr 2
|
IH
BOLT, 3/8 x 1 C-Z sq-nk crg Superseded by part number: 88682
|
| . . |
18684R1
|
[2] |
BOLT,Sht Sq Nk, 3/8" - 16 x 1 1/4", Gr 2
|
IH
3/8 x 1-1/4 znp sq-nk crg Superseded by part number: 550796R1
|
| . . |
120377
|
[4] |
NUT,3/8" - 16, Gr 5
|
IH
Superseded by part number: 280136
|
| . . |
120382
|
[4] |
LOCK WASHER,Helical Spring, 3/8"
|
IH
WASHER, LOCK, 3/8" Superseded by part number: 80680
|
| . . |
469668R1
|
[2] |
WASHER
|
IH
13/32 x 3/4 x 16 ga znp Superseded by part number: 86632580
|
| 2. |
202584C1
|
[1] |
LARGE PLATE
|
IH
FILLER, breast plate LH
|
| 3. |
667779R31
|
[1] |
PLATE
|
IH
ASSY, breast Superseded by part number: 210568C91
|
| 4. |
22803R1
|
[1] |
PIN,1/2" x 9 1/4"
|
IH
1/2 x 9-1/4 C-Z std hd Superseded by part number: 204173C1
|
| . . |
18481R1
|
[1] |
COTTER PIN,3/16" x 1"
|
IH
PIN, SPLIT (COTTER), 3/16" x 1" Superseded by part number: 432-1216
|
| 5. |
662007R2
|
[2] |
RETAINER
|
IH
hay
|
| 6. |
668869R1
|
[2] |
SPRING
|
IH
hay retainer
|
| 7. |
662009R4
|
[2] |
ANCHOR
|
IH
knotter
|
| . . |
19019R1
|
[2] |
CARRIAGE BOLT,#3, 3/8" - 16 x 1", Gr 2
|
IH
BOLT, 3/8 x 1 C-Z no. 3 plow Superseded by part number: 419-3616
|
| . . |
18494R1
|
[1] |
BOLT,Hex, 3/8" - 16 x 1", Gr 2
|
IH
3/8 x 1 C-Z hex-hd mach Superseded by part number: 424-616
|
| . . |
138489
|
[2] |
LOCK WASHER,Ext Tooth, 3/8"
|
IH
WASHER, LOCK, Ext Tooth, 3/8" Superseded by part number: 280295
|
| 8. |
662146R1
|
[1] |
BRACKET
|
IH
hay retainer pivot upper
|
| . . |
18495R1
|
[1] |
BOLT,Hex, 3/8" - 16 x 1 1/4", Gr 2
|
IH
3/8 x 1-1/4 C-Z hex-hd mach Superseded by part number: 180124
|
| 9. |
202585C2
|
[1] |
FILLER
|
IH
breast plate RH
|
| 10. |
667810R21
|
[1] |
FRAME
|
IH
W/BUSHING, knotter drive
|
| . . |
189619R1
|
[1] |
BOLT, 5/8 x 2-1/4 C-Z hex-hd mach
|
|
| . . |
280374
|
[1] |
NUT,Hex, 5/8" - 11, Gr 5
|
NH
5/8-11 C-Z hex
|
| . . |
492-11062
|
[1] |
BEARING WASHER,5/8"
|
CAS
WASHER, LOCK, 5/8" Superseded by part number: 86729275
|
| 11. |
109461
|
[2] |
LUBE NIPPLE,1/8"-27 x .66 lg
|
IH
NIPPLE, LUBE, , PTF 1/8"-27 x .66 lg Superseded by part number: 80710
|
| 12. |
667811R1
|
[2] |
BUSHING
|
IH
trip arm stud
|
| 13. |
662112R1
|
[2] |
SPRING
|
IH
twine retainer
|
| . . |
216378
|
[4] |
RIVET
|
IH
1/4 x 7/16 znp csk-hd small solid
|
| . . |
18508R1
|
[1] |
CARRIAGE BOLT,Short Nk, 3/8" - 16 x 3/4", Gr 2, Full Thd
|
IH
BOLT, 3/8 x 3/4 C-Z sq-nk crg Superseded by part number: 86508748
|
| . . |
19009R1
|
[2] |
CARRIAGE BOLT,#3, 5/16" - 18 x 1 1/2", Gr 2
|
IH
BOLT, 5/16 x 1-1/2 znd no. 3 plow
|
| . . |
19007R1
|
[2] |
PLOW BOLT,#3, 5/16" - 18 x 1", Gr 2
|
IH
BOLT, 5/16 x 1 plow
|
| . . |
120376
|
[4] |
NUT,5/16"-18, G5
|
IH
Superseded by part number: 9635082
|
| . . |
80681
|
[4] |
LOCK NUT,5/16"
|
NH
WASHER, LOCK, 5/16" Superseded by part number: 83990583
|
| 14. |
204631C91
|
[2] |
FINGER
|
CAS
W/RIVETS, base plate, replaces 495412R71 and 668975R12 Superseded by part number: 88929, 204629C1
|
| . . |
216380
|
[4] |
RIVET
|
IH
1/4 x 7/8 znp csk-hd small solid Superseded by part number: 104168
|
| . . |
123821
|
[4] |
RIVET
|
IH
1/4 x 5/8 znp csk-hd small solid Superseded by part number: 104167
|
| 15. |
495929R2
|
[2] |
WEDGE
|
IH
hay retainer narrow
|
| 16. |
495930R1
|
[1] |
WEDGE
|
IH
hay retainer wide
|
| . . |
18421R1
|
[2] |
CARRIAGE BOLT,Short Sq Nk, 7/16" - 14 x 1", Gr 2
|
IH
BOLT, CARRIAGE, Short NK, 7/16"-14 x 1", G5, Full Thd Superseded by part number: 412-716
|
| . . |
NLS
|
[2] |
NO LONGER SERVICED
|
BAS
NUT, 7/16-14 C-Z hex.
|
| . . |
120383
|
[2] |
LOCK WASHER,Helical Spring, 7/16"
|
IH
WASHER, LOCK, 7/16" Superseded by part number: 81547
|
| . . |
113225
|
[4] |
RIVET,Csk, 3/16" x 9/16"
|
CAS
3/16 x 9/16 90 deg csk-hd
|
| . . |
17064R1
|
[2] |
LOCK PIN,1/8" x 5/8", Slotted
|
IH
Pin, 1/8" x 5/8", Slotted Superseded by part number: 20948R1
|
| . . |
104168
|
[4] |
RIVET,Csk, 1/4" x 7/8"
|
IH
Superseded by part number: 88929
|
| 19. |
87414
|
[1] |
LUBE NIPPLE,1/4" - 28
|
NH
FITTING, 1/4-28 str self tap, lub
|
| 20. |
674263R1
|
[3] |
BUSHING
|
IH
packer crank
|
| 22. |
674101R1
|
[1] |
FILLER
|
IH
knotter drive frame upper
|
| . . |
18779R1
|
[3] |
BOLT,Hex, 3/8"-16 x 1 1/2", Gr 2
|
IH
3/8 x 1-1/2 C-Z hex-hd mach Superseded by part number: 179843
|
| . . |
20803R1
|
[2] |
WASHER
|
IH
13/32 x 1 x 16 ga C-Z, see note A, long wear part Superseded by part number: 87613212
|
| . . |
204017C92
|
[1] |
STRIP
|
IH
BREAST PLATE WEAR STRIP PKG., consists of
|
| . . |
204226C92
|
[1] |
|
P
KNOTTER DISK SERVICE PKG., consist of
|
| 1. |
201623C2
|
[2] |
DISC
|
IH
DISK, cord holder rear
|
| 2. |
313678R1
|
[2] |
SPRING
|
IH
twine end helper
|
| 3. |
201637C2
|
[2] |
SPRING
|
IH
twine end retainer
|
