| 1. |
663364R1
|
[1] |
BUSHING
|
IH
packer crank Superseded by part number: 667844R1
|
| 2. |
109461
|
[2] |
LUBE NIPPLE,1/8"-27 x .66 lg
|
IH
NIPPLE, LUBE, , PTF 1/8"-27 x .66 lg Superseded by part number: 80710
|
| 3. |
667810R21
|
[1] |
FRAME
|
IH
W/BUSHINGS, twister drive
|
| . . |
18619R1
|
[1] |
BOLT,Hex, 5/8" - 11 x 2 1/4", Gr 2
|
IH
5/8 x 2-1/4 znd hex-hd mach Superseded by part number: 271563
|
| . . |
280374
|
[1] |
NUT,Hex, 5/8" - 11, Gr 5
|
NH
5/8-11 znd hex.
|
| . . |
492-11062
|
[1] |
BEARING WASHER,5/8"
|
CAS
WASHER, LOCK, 5/8" Superseded by part number: 86729275
|
| . . |
21471R1
|
[1] |
WASHER
|
IH
21/32 x 1 x 11 ga C-Z Superseded by part number: 87613215
|
| . . |
18779R1
|
[4] |
BOLT,Hex, 3/8"-16 x 1 1/2", Gr 2
|
IH
3/8 x 1-1/2 znd hex-hd mach Superseded by part number: 179843
|
| . . |
120377
|
[4] |
NUT,3/8" - 16, Gr 5
|
IH
Superseded by part number: 280136
|
| . . |
120382
|
[4] |
LOCK WASHER,Helical Spring, 3/8"
|
IH
WASHER, LOCK, 3/8" Superseded by part number: 80680
|
| . . |
20803R1
|
[2] |
WASHER
|
IH
13/32 x 1 x 16 ga C-Z Superseded by part number: 87613212
|
| 4. |
674263R1
|
[3] |
BUSHING
|
IH
packer crank
|
| 5. |
219-37
|
[1] |
LUBE NIPPLE,45 Degree Elbow, 1/4" - 28 NPTF
|
CAS
FITTING, 1/4-28, 45 deg angle lub Superseded by part number: 87569
|
| 6. |
674334R2
|
[2] |
GUIDE
|
IH
wire tail upper
|
| . . |
18677R1
|
[4] |
CARRIAGE BOLT,Short Nk, 5/16" - 18 x 2 1/2", Gr 2
|
IH
BOLT, 5/16 x 2-1/2 znd sq-nk crg Superseded by part number: 280622
|
| . . |
120376
|
[4] |
NUT,5/16"-18, G5
|
IH
Superseded by part number: 9635082
|
| . . |
23060R1
|
[4] |
LOCK WASHER,Int Tooth, 5/16"
|
IH
WASHER, 5/16 znd int-tooth lock Superseded by part number: 193-67
|
| 7. |
674333R1
|
[2] |
FINGER
|
IH
base plate
|
| 8. |
667811R1
|
[4] |
BUSHING
|
IH
trip arm stud
|
| 9. |
201674C1
|
[2] |
BRACKET
|
IH
twist
|
| . . |
12872R1
|
[4] |
BOLT,Short NK, 5/16"-18 x 1", G2, Full Thd
|
IH
CARRIAGE, Short NK, 5/16"-18 x 1", G2, Full Thd Superseded by part number: 598803R1
|
| . . |
80681
|
[4] |
LOCK NUT,5/16"
|
NH
WASHER, LOCK, 5/16" Superseded by part number: 83990583
|
| 10. |
201675C1
|
[2] |
FINGER
|
IH
tail guide and mount
|
| . . |
16888R1
|
[2] |
HARDWARE,Short NK, 5/16"-18 x 1 1/4", G2
|
IH
BOLT, 5/16 x 1-1/4 znd sq-nk crg Superseded by part number: 598804R1
|
| . . |
90560H
|
[2] |
CLEVIS PIN,1/2" x 2.766"
|
IH
PIN, 1/2 x 2-49/64 rod end Superseded by part number: 27-8276
|
| . . |
178373R1
|
[4] |
WASHER
|
IH
17/32 x 1 x 16 ga C-Z Superseded by part number: 495-51053
|
| . . |
648002
|
[2] |
1/8" x 3/4"
|
KNIFE
|
| 11. |
202619C2
|
[1] |
FILLER
|
IH
base plate RH
|
| 12. |
495930R1
|
[1] |
WEDGE
|
IH
hay retainer wide
|
| . . |
18421R1
|
[2] |
CARRIAGE BOLT,Short Sq Nk, 7/16" - 14 x 1", Gr 2
|
IH
BOLT, CARRIAGE, Short NK, 7/16"-14 x 1", G5, Full Thd Superseded by part number: 412-716
|
| . . |
NLS
|
[2] |
NO LONGER SERVICED
|
BAS
NUT, 7/16-14 znd hex.
|
| . . |
120383
|
[2] |
LOCK WASHER,Helical Spring, 7/16"
|
IH
WASHER, LOCK, 7/16" Superseded by part number: 81547
|
| 13. |
495929R2
|
[2] |
WEDGE
|
IH
hay retainer narrow
|
| . . |
17351R1
|
[2] |
CARRIAGE BOLT,Short Sq Nk, 3/8" - 16 x 1", Gr 2
|
IH
BOLT, 3/8 x 1 znd sq-nk crg Superseded by part number: 88682
|
| . . |
18684R1
|
[2] |
BOLT,Sht Sq Nk, 3/8" - 16 x 1 1/4", Gr 2
|
IH
3/8 x 1-1/4 znd sq-nk crg Superseded by part number: 550796R1
|
| 14. |
674326R1
|
[1] |
PLATE
|
IH
ASSY, wire base
|
| . . |
19019R1
|
[3] |
CARRIAGE BOLT,#3, 3/8" - 16 x 1", Gr 2
|
IH
BOLT, 3/8 x 1 znd No. 3 plow Superseded by part number: 419-3616
|
| . . |
469668R1
|
[3] |
WASHER
|
IH
13/32 x 3/4 x 16 ga C-Z Superseded by part number: 86632580
|
| . . |
19020R1
|
[2] |
PLOW BOLT,#3, 3/8" - 16 x 1 1/4", Gr 2
|
IH
BOLT, 3/8 x 1-1/4 znd No. 3 plow, 430 Baler Superseded by part number: 19031R1
|
| . . |
19009R1
|
[2] |
CARRIAGE BOLT,#3, 5/16" - 18 x 1 1/2", Gr 2
|
IH
BOLT, 5/16 x 1-1/2 znd No. 3 plow
|
| 15. |
200414C1
|
[1] |
|
P
FILLER, base plate LH, serial numbers, 430W 001195 thru 001403, 440W 001304 thru 001578
|
| 15. |
202618C1
|
[1] |
FILLER
|
IH
base plate LH, serial numbers, 430W 001404 and above, 440W 001579 and above
|
| 16. |
674346R2
|
[1] |
SUPPORT
|
IH
twister shaft brg Superseded by part number: 1281314C1
|
| . . |
18494R1
|
[3] |
BOLT,Hex, 3/8" - 16 x 1", Gr 2
|
IH
3/8 x 1 znd hex-hd mach Superseded by part number: 424-616
|
| 17. |
667839R2
|
[1] |
SUPPORT
|
IH
PLATE, twister shaft brg support
|
| . . |
18495R1
|
[2] |
BOLT,Hex, 3/8" - 16 x 1 1/4", Gr 2
|
IH
3/8 x 1-1/4 znd hex-hd Superseded by part number: 180124
|
| . . |
22264R1
|
[2] |
WASHER
|
IH
13/32 x 1 x 7 ga C-Z Superseded by part number: 495-81138
|
| 18. |
674336R1
|
[8] |
PIVOT
|
IH
hay retainer
|
| . . |
18474R1
|
[8] |
BOLT,Hex, 5/16" - 18 x 1", Gr 2
|
IH
5/16 x 1 hex-hd mach znd Superseded by part number: 424-516
|
| 19. |
674337R1
|
[4] |
RETAINER
|
IH
hay
|
| . . |
21964R1
|
[4] |
HEADED PIN,3/8" x 1 1/2"
|
IH
PIN, 3/8 x 1-1/2 C-Z std-hd Superseded by part number: 439-1624
|
| 20. |
665192R1
|
[4] |
SPRING
|
IH
hay retainer
|
| 21. |
674335R1
|
[4] |
BRACKET
|
IH
hay retainer
|
| . . |
19328R1
|
[4] |
LOCK PIN,3/8" x 3/4", Slotted
|
IH
Superseded by part number: 38-12412
|
