斗山零件查询OIL COOLER PIPING(2) SOLAR 185W-V Doosan parts catalog online
广数供应链运营团队, 15 02月, 2025，浏览：
987 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| -. |
420212-12021
|
[-] |
|
|
| -. |
400-01223B
|
[-] |
OIL COOLER PIPING
|
|
| 1. |
140-01364C
|
[1] |
PIPE;SUCTION
|
|
| 13. |
2185-1776D40
|
[1] |
HOSE-390L
|
|
| 14. |
S8030161
|
[2] |
O-RING
|
|
| 17. |
2180-1026D32
|
[1] |
O-RING
|
|
| 22. |
140-01360A
|
[2] |
PIPE
|
|
| 42. |
S8470095
|
[4] |
CLAMP;HOSE
|
|
| 46. |
2185-1776D47
|
[1] |
HOSE-350L
|
|
| 64. |
S2221566
|
[4] |
BOLT
|
|
| 65. |
K1026273
|
[4] |
WASHER;HARD
|
|
| 65. |
S5110903
|
[4] |
WASHER
|
K1026273
|
| 66. |
S2205066
|
[8] |
BOLT
|
|
| 67. |
S8500044
|
[4] |
CLAMP;HOSE
|
|
| 9. |
2185-1002D93
|
[1] |
HOSE
|
|
