斗山零件查询OIL COOLER PIPING(3) SOLAR 185W-V Doosan parts catalog online
广数供应链运营团队, 15 02月, 2025，浏览：
966 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| -. |
400-01223B
|
[-] |
OIL COOLER PIPING
|
|
| -. |
420212-12021
|
[-] |
|
|
| 12. |
2184-1036D14
|
[1] |
HOSE PF1/2-1420L
|
|
| 16. |
S8000291
|
[1] |
O-RING
|
|
| 20. |
S8000181
|
[4] |
O-RING
|
|
| 25. |
2181-1126D6
|
[2] |
ADAPTER
|
|
| 45. |
2181-1951D5
|
[1] |
TEE
|
|
| 47. |
2184-1036D255
|
[1] |
HOSE PF1/2-1300L
|
|
| 48. |
2184-1096D27
|
[1] |
HOSE PF1/2-650L
|
|
| 52. |
2184-1045D176
|
[1] |
HOSE PF1/4-1300L
|
|
| 53. |
2181-1951D19
|
[1] |
TEE
|
|
| 54. |
2181-1702D4
|
[1] |
ELBOW
|
|
| 55. |
S8000111
|
[1] |
O-RING
|
|
| 56. |
2181-2638D3
|
[1] |
ADAPTER PFO3/4-PF1
|
|
| 57. |
2181-1702D11
|
[1] |
ELBOW PFO1-PF1
|
|
| 58. |
2184-1026D406
|
[1] |
HOSE PF1-1950L
|
|
| 59. |
S8000231
|
[1] |
O-RING
|
|
