| 1. |
585856R91
|
[1] |
|
P
VALVE ASSY, top terminating, plunger stop pivot
|
| 1. |
586983R1
|
[1] |
|
P
ADAPTER, 1/8 PTF 90 deg elbow
|
| 1. |
109461
|
[1] |
LUBE NIPPLE,1/8"-27 x .66 lg
|
IH
NIPPLE, LUBE, , PTF 1/8"-27 x .66 lg Superseded by part number: 80710
|
| 2. |
362120R1
|
[5] |
CLAMP,9.53mm ID, 10.32mm Bolt Hole, P Type
|
IH
CLIP, for 3/8 bolt
|
| . . |
18765R1
|
[4] |
BOLT,Hex, 5/16" - 18 x 1 1/2", Gr 2
|
IH
5/16 x 1-1/2 znd hex-hd mach Superseded by part number: 180083
|
| . . |
120376
|
[4] |
NUT,5/16"-18, G5
|
IH
Superseded by part number: 9635082
|
| . . |
80681
|
[4] |
LOCK NUT,5/16"
|
NH
WASHER, LOCK, 5/16" Superseded by part number: 83990583
|
| . . |
619855R1
|
[4] |
WASHER
|
IH
11/32 x 3/4 x 16 ga C-Z Superseded by part number: 86637953
|
| . . |
21496R1
|
[4] |
WASHER
|
IH
11/32 x 3/4 x 11 ga C-Z Superseded by part number: 86624142
|
| 4. |
668599R91
|
[1] |
|
P
VALVE ASSY, top and 90 deg elbow, cord holder pinion shaft upper
|
| 4. |
20204R1
|
[1] |
ADAPTER,90 Degree, 1/4"-1/8 NPTF
|
IH
1/4-28 male x 1/8 pipe female 90 deg elbow Superseded by part number: 219-402
|
| 6. |
668598R91
|
[2] |
|
P
VALVE ASSY, top and tee, knotter frame
|
| 6. |
21347R1
|
[2] |
ADAPTER,45 Degree, 1/4"-1/8 NPTF
|
IH
1/4-28, 45 deg. angle elbow Superseded by part number: 87020437
|
| 8. |
588291R91
|
[2] |
|
P
VALVE ASSY, 90 deg terminating, wire hook shaft, left and right
|
| 10. |
585854R91
|
[2] |
|
P
VALVE ASSY, top terminating, wire hook shaft, lower left and right
|
| 13. |
631345R91
|
[1] |
|
P
VALVE ASSY, 90 deg elbow, front bearing, rear packer shaft
|
| 21. |
585860R91
|
[2] |
|
P
VALVE ASSY, 90 deg terminating, wire holder shaft, upper left and right
|
| 23. |
585857R91
|
[2] |
|
P
VALVE ASSY, 90 deg terminating, wire holder shaft, lower left and right
|
| 27. |
668555R1
|
[2] |
|
P
CLIP, 3/16 tube open
|
| . . |
167163
|
[2] |
SELF-TAP SCREW,Cross Pan Hd, #10 x 1/2"
|
IH
SCREW, 10-32 x 1/2 znd cr-rd-hd tap Superseded by part number: 261-6458
|
| 28. |
674950R91
|
[1] |
|
P
PUMP ASSY, lubrication for components see list of parts under detail of pump and timer
|
