纽荷兰零件查询(E200SRLC) - CRAWLER EXCAVATOR BTW LA04-01506 - LA04-01625 (07-008) - CYLINDER ASSY, BUCKET New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
845 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YB01V00011F1 | [1] | HYDRAULIC CYLINDER | KOBASSY, BUCKET Superseded by part number: YB01V00011F2 |
| . . | YB01V00011F2 | [1] | HYDRAULIC CYLINDER | KOBASSY, BUCKET |
| 1. | NSS | [1] | NOT SERVICED SEPARATELY | CONTUBE,CYLINDER |
| 3. | YB01V00011S003 | [1] | CYLINDER | KOBHEAD |
| 4. | 2438U1949S4 | [1] | BUSHING | KOB |
| 5. | 2438U1949S5 | [1] | RING | KOBRETAINING |
| 6. | LP01V00007S006 | [1] | RUBBER BLOCK | KOBFOR F1 ONLY |
| 7. | 2438U814S31 | [1] | RING | KOBU |
| 8. | 2438U814S32 | [1] | RING | KOBBACK UP |
| 9. | LP01V00007S009 | [1] | RING | KOBWIPER |
| 10. | ZD12G10000 | [1] | O-RING,99.40mm ID x 105.60mm OD x 3.10mm | KOB |
| 11. | PZ01V00003S008 | [1] | RING | KOBBACK UP |
| 12. | ZS23C14065 | [12] | BOLT,Hex Socket Head, M14 x 65mm | KOBCAPSCREW |
| 13. | YB01V00011S013 | [1] | BUSHING | KOBCUSHION |
| 14. | YB01V00011S014 | [1] | SEAL | KOBCUSHION |
| 15. | YM01V00009S015 | [1] | PISTON | KOB |
| 16. | 2438U676S21 | [1] | RING | KOBSEAL |
| 17. | YM01V00009S017 | [2] | RING | KOBBACK-UP |
| 18. | YM01V00009S018 | [2] | RING | KOBRING SLIDE |
| 19. | 2438U814S23 | [2] | RING | KOBSLIDE |
| 20. | 2438U1094S21 | [1] | SHIM | KOB |
| 21. | YM01V00009S020 | [1] | NUT | KOB |
| 22. | 2438U999S21 | [1] | SET SCREW | KOBSET |
| 23. | 2436U330S16 | [1] | BALL | KOB |
| 24. | YB01V00011S024 | [2] | BUSHING | KOB |
| 25. | YB01V00011S025 | [4] | MUDSCRAPER RING | KOBWIPER |
| 26. | YM01V00009S026 | [1] | STRAP | KOBASSY |
| 27. | LE01V00009S028 | [1] | BAND | KOB |
| 28. | ZS18C10035 | [2] | SCREW,Hex, M10 x 35mm | KOBM10x1.50x35mm |
| 29. | ZW26X10000 | [2] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 30. | YM01V00009S006 | [1] | RING | KOBRING, BUFFER, FOR F2 ONLY Superseded by part number: YM01V00009S031 |
| . . | YB01V00011R100 | [1] | KIT | KOBREPAIR, ROD SIDE CONSISTS OF Ref. 7(1), 8(1), 9(1), 10(1), 11(1), 30(1), FOR F2 ONLY |
| . . | YM01V00009R200 | [1] | REPAIR KIT | KOBPISTON SIDE CONSISTS OF Ref. 16(1), 17(2), 18(2), 19(2) |
| . . | YB01V00011R300 | [1] | KIT | KOBREPAIR, ALLCROD+PISTON) CONSISTS OF Ref. 7(1), 8(1), 9(1), 10(1), 11(1), 16(1), 17(2), 18(2), 19(2), 30(1), FOR F2 ONLY |
| . . | YB01V00011R400 | [1] | HYDRAULIC CYLINDER | KOBREPAIR KIT, CONSISTS OF Ref. 1(1), 24(1) |
| . . | YB01V00011R500 | [1] | SEAL KIT | KOBREPAIR KIT, CONSISTS OF Ref. 2(1), 24(1) |
