纽荷兰零件查询(E200SRLC) - CRAWLER EXCAVATOR BTW LA04-01506 - LA04-01625 (08-013) - WATER PUMP AND CORROSION RESISTER New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
147 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 3. | VI8943706610 | [1] | GASKET | KOBGASKET; PUMP TO C/BL |
| 4B. | VI5878143200 | [1] | REPAIR KIT; WATER PUMP | |
| 7B. | VI1136411870 | [1] | PULLEY | KOBPULLEY; WATER PUMP (2-GR00VE), TCY ONLY |
| 7B. | VI1136411650 | [1] | PULLEY | KOBPULLEY; WATER PUMP (2-GR00VE) |
| 9. | VI9091801520 | [1] | RING; SNAP, WATER PUMP | |
| 11. | VI5136340020 | [1] | SPACER; BRG, WATER PUMP | |
| 16. | VI5096250550 | [1] | SEAL; OIL, WATER PUMP | |
| 18. | VI8972322500 | [1] | IMPELLER; WATER PUMP | |
| 20. | VI8972322470 | [1] | COVER; WATER PUMP | |
| 26. | VI5136390010 | [1] | COVER; DUST,WATER PUMP | |
| 27C. | VI1098001700 | [1] | BEARING; WATER PUMP | |
| 28. | VI1095030700 | [1] | WASHER; WATER PUMP | |
| 29. | VI1136310740 | [1] | SHAFT; WATER PUMP | |
| 30. | VI9099521430 | [1] | RING; SNAP, WATER PUMP SHAFT | |
| 31. | VI8972236600 | [1] | PIPE; SUCTION, INL | |
| 31. | VI8972498951 | [1] | PIPE; SUCTION, INL | |
| 34. | VI9030908200 | [3] | SCREW | KOBSCREW; COVER TO BODY, WATER PUMP |
| 36. | VI0280810350 | [1] | BOLT; WATER PUMP TO C/BL (M10X35 FLANGE) | |
| 36. | VI0280810450 | [2] | BOLT; WATER PUMP TO C/BL (Ml 0X45 FLANGE) | |
| 36. | VI0280810700 | [1] | BOLT; WATER PUMP TO C/BL (M10X70 FLANGE) | |
