| 1. |
662345R1
|
[1] |
|
P
BRACKET, battery support, rear (B)
|
| . . |
17426R1
|
[1] |
BOLT,Hex, 3/8" - 16 x 1", Gr 2
|
IH
mach., hex-hd., 3/8-16NC x 1" (B) Superseded by part number: 24840R1
|
| . . |
102635
|
[1] |
NUT,3/8"-16, G5
|
IH
(B) 3/8"-16, G5 Superseded by part number: 280136
|
| . . |
103321
|
[1] |
LOCK WASHER,3/8"
|
IH
WASHER, LOCK, (B) 3/8" Superseded by part number: 80680
|
| 2. |
662347R2
|
[1] |
|
P
SUPPORT, battery box
|
| . . |
80280503
|
[2] |
CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5, Full Thd
|
BEL
BOLT, carriage, 3/8-16NC x 1" (B)
|
| . . |
17446R1
|
[1] |
BOLT,3/8" - 16 x 1 1/4", Gr 2
|
IH
mach., hex-hd., 3/8-16NC x 1-1/4" (B) Superseded by part number: 88011
|
| . . |
NLS
|
[1] |
NO LONGER SERVICED
|
BAS
hex., 7/16-14NC (B)
|
| . . |
114672
|
[2] |
SCREW
|
IH
slotted-fl-hd., 3/8-16NC x 1" (B)
|
| . . |
110235
|
[1] |
SCREW, slotted-fl-hd., 7/16-14NC x 3/4" (B)
|
|
| . . |
103322
|
[1] |
LOCK WASHER,7/16"
|
IH
WASHER, LOCK, (B) 7/16" Superseded by part number: 81547
|
| 3. |
661226R91
|
[1] |
|
P
COVER, battery box (Welded assembly) (B)
|
| 4. |
51690D
|
[2] |
|
P
RUBBER, battery hold-down (B)
|
| 5. |
661232R91
|
[1] |
|
P
BODY, battery box (Welded asembly) (B)
|
| 6. |
50939DA
|
[2] |
SPECIAL BOLT,1/4" - 20 x 2 1/4"
|
IH
battery box cover (B)
|
| . . |
665621R1
|
[2] |
|
P
NUT, wing, 1/4-20NC (B)
|
| . . |
95-11028
|
[2] |
WASHER,1/4"
|
CAS
plain, 9/32" ID x 5/8" OD x no. 16 ga. (B)
|
| 7. |
372656R91
|
[1] |
|
P
BATTERY, (Auto-lite) (6 volt) (B)
|
| 8. |
661236R1
|
[1] |
|
P
BOX, battery, front (B)
|
| 9. |
659967R1
|
[1] |
|
P
SUPPORT, tractor battery cable (C)
|
| . . |
17411R1
|
[2] |
BOLT,Hex, 5/16"-18 X 3/4", G2
|
IH
mach., hex-hd., 5/16-18NC x 3/4" (C) Superseded by part number: 179816
|
| . . |
9635082
|
[2] |
NUT,5/16" - 18, Gr 5
|
NH
hex., 5/16-18NC (C)
|
| . . |
103320
|
[2] |
LOCK WASHER,5/16"
|
IH
WASHER, LOCK, (C) 5/16" Superseded by part number: 322358, 83990583
|
| . . |
69510DA
|
[1] |
CABLE
|
IH
battery ground (B) Superseded by part number: 71198C1
|
| . . |
17412R1
|
[1] |
BOLT,Hex, 3/8" - 16 x 3/4", Gr 2
|
IH
mach., hex-hd., 3/8-16NC x 3/4" (B) Superseded by part number: 86500692
|
| . . |
663457R91
|
[1] |
|
P
CABLE, battery starting switch (B)
|
| . . |
662341R91
|
[1] |
|
P
CABLE, starter and ground, engine (C)
|
| . . |
17766
|
[1] |
BOLT, mach., hex-hd., 3/8-16NC x 4-1/2" (C)
|
|
| . . |
102637
|
[1] |
NUT,1/2"-13, G5
|
IH
(C) 1/2"-13, G5 Superseded by part number: 280431
|
| . . |
103323
|
[1] |
LOCK WASHER,1/2"
|
IH
WASHER, LOCK, (C) 1/2" Superseded by part number: 87326976
|
| . . |
659962R91
|
[1] |
|
P
CABLE, tractor battery (C)
|
| . . |
56278D
|
[1] |
CLIP
|
IH
cable (For 3/8" bolt) (B & C)
|
| . . |
56277D
|
[1] |
|
P
CLIP, cable (For 1/2" bolt) (B)
|
| . . |
1001721R1
|
[1] |
|
P
DECALCOMANIA, "arrow" (On crank wheel)
|
| . . |
52118D
|
[2] |
GROMMET
|
IH
battery box (B)
|
| . . |
662425R91
|
[1] |
JACK, lifting, assembly (For listing of component parts see "Jackstand attachment" unit)
|
|
