662428R91
|
[1] |
HYDRAULIC BALE DENSITY CONTROL (Machine attachment), Composed of -
|
|
| 1. |
662455R91
|
[1] |
|
P
CHANNEL, tension, bale chamber, upper (Welded assembly)
|
| 2. |
18130R1
|
[2] |
BOLT, tie, bale tension channel
|
|
| . . |
102639
|
[4] |
NUT,5/8"-11, G5
|
IH
Superseded by part number: 280374
|
| . . |
12258R1
|
[2] |
WASHER
|
IH
plain, 21/32" ID x 1-1/4" OD x no. 11 ga. Superseded by part number: 25711R1
|
| 3. |
662458R91
|
[1] |
|
P
BEAM, upper tension channel (Welded assembly)
|
| . . |
Q107
|
[2] |
WASHER
|
IH
plain, 13/32" ID x 1-3/16" OD x no. 16 ga. Superseded by part number: 195-104
|
| 4. |
PO91
|
[1] |
SPRING
|
IH
retainer, tension channel
|
| 5. |
663110R1
|
[1] |
|
P
PIN, pivot, pump and star wheel frame
|
| . . |
432-1216
|
[2] |
COTTER PIN,3/16" x 1"
|
CAS
Pin, Split (Cotter), 3/16" x 1"
|
| 6. |
659420R1
|
[1] |
|
P
STUD, adjusting spring
|
| . . |
103384
|
[1] |
COTTER PIN,1/8" x 3/4"
|
IH
Pin, Split (Cotter), 1/8" x 3/4" Superseded by part number: 80755
|
| 7. |
516569R1
|
[1] |
WASHER
|
IH
spring
|
| 8. |
659430R1
|
[1] |
|
P
SPRING, pressure adjustment
|
| 9. |
659426R1
|
[1] |
|
P
NUT, adjusting spring
|
| 10. |
659413R91
|
[1] |
|
P
SHIELD, pump and star wheel (Welded assembly)
|
| 11. |
659424R1
|
[1] |
|
P
ROD, hinge, shield
|
| . . |
NLS
|
[2] |
NO LONGER SERVICED
|
BAS
PIN, cotter, 1/16 x 1/2"
|
| . . |
Q392
|
[4] |
WASHER
|
CAS
plain, 9/32" ID x 3/4" OD x no. 16 ga. Superseded by part number: 495-21031
|
| 12. |
659403R1
|
[1] |
|
P
WHEEL, star (Welded assembly)
|
| . . |
18428R1
|
[1] |
BOLT, carriage, 1/2-13NC x 3-1/2"
|
|
| . . |
425-128
|
[1] |
SLOTTED NUT,1/2"-13, G5
|
CAS
NUT, slotted, hex., 1/2-13NC
|
| . . |
103374
|
[1] |
COTTER PIN,3/32" x 1"
|
IH
Pin, Split (Cotter), 3/32" x 1" Superseded by part number: 280251
|
| 13. |
109368
|
[1] |
FITTING, lubrication, straight, 5/16"
|
|
| 14. |
659404R91
|
[1] |
|
P
FRAME, pump and star wheel (Welded assembly)
|
| 15. |
660199R1
|
[1] |
|
P
STRAP, bale chamber
|
