凯斯零件查询(46) - MCCORMICK-INTERNATIONAL PICK UP RECTANGULAR BALER (1/57-12/63) (81) - HYDRAULIC BALE DENSITY CONTROL, HYDRAULIC JACK Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
200 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
NLS
|
[2] |
NO LONGER SERVICED
|
BAS
tube (On pressure tube)
|
| 2. |
662561R11
|
[1] |
|
P
TUBE, pressure, w/tube nuts
|
| 3. |
110200
|
[1] |
CONNECTOR, ELEC
|
IH
ADAPTER, hydraulic jack Superseded by part number: 222-807
|
| . . |
9635082
|
[4] |
NUT,5/16" - 18, Gr 5
|
NH
hex., 5/16-18NC
|
| . . |
113916
|
[4] |
SCREW
|
IH
slotted-fil-hd., 5/16-18NC x 1-1/4"
|
| . . |
103320
|
[4] |
LOCK WASHER,5/16"
|
IH
WASHER, LOCK, 5/16" Superseded by part number: 322358, 83990583
|
| 5. |
659557R1
|
[2] |
RING
|
IH
O-RING, piston and bearing Superseded by part number: 707220R1
|
| 6. |
659551R91
|
[1] |
|
P
ROD, piston (Welded assembly)
|
| 7. |
659555R1
|
[1] |
|
P
BEARING, piston rod
|
| 8. |
659554R1
|
[1] |
PLATE
|
IH
end
|
| . . |
110500
|
[2] |
SCREW,Slotted Rd Hd, #10-24 x 1/2"
|
IH
slotted-rd-hd., no. 10-24 x 1/2" Superseded by part number: 159920
|
| . . |
106497
|
[2] |
LOCK WASHER,#10
|
IH
WASHER, LOCK, #10 Superseded by part number: 80684
|
| 9. |
659558R1
|
[1] |
O-RING,1.046" ID x 0.139" Width
|
IH
bearing
|
| 10. |
659556R1
|
[1] |
WASHER
|
IH
back-up Superseded by part number: A35899
|
| 11. |
17086R1
|
[1] |
LOCK PIN,3/8" x 2 1/2", Slotted
|
IH
PIN, 3/8" x 2 1/2", Slotted Superseded by part number: 84158586
|
| 12. |
659559R1
|
[1] |
|
P
RING, lock, hydraulic jack
|
| 13. |
963236R91
|
[1] |
|
P
JACK, hydraulic, assembly
|
