| 1. |
667809R1
|
[1] |
|
P
SUPPORT, knotter shaft bearing
|
| . . |
80280503
|
[2] |
CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5, Full Thd
|
BEL
BOLT, cge. 3/8 x 1
|
| . . |
15581R1
|
[2] |
BOLT,3/8"-16 x 1 1/2", G2
|
IH
pl. 3/8 x 1-1/2 Superseded by part number: 19021R1, 118-141
|
| . . |
102635
|
[4] |
NUT,3/8"-16, G5
|
IH
Superseded by part number: 280136
|
| . . |
103321
|
[4] |
LOCK WASHER,3/8"
|
IH
WASHER, LOCK, 3/8" Superseded by part number: 80680
|
| 2. |
662149R1
|
[1] |
|
P
FILLER, breast plate L.
|
| 3. |
667779R31
|
[1] |
PLATE
|
IH
breast cpt. Superseded by part number: 210568C91
|
| 4. |
665078R1
|
[1] |
PIN,1/2" x 9 1/4"
|
IH
hay retainer pivot
|
| . . |
432-1216
|
[1] |
COTTER PIN,3/16" x 1"
|
CAS
Pin, Split (Cotter), 3/16" x 1"
|
| 5. |
662007R2
|
[2] |
RETAINER
|
IH
hay
|
| 6. |
668869R1
|
[2] |
SPRING
|
IH
ANCHOR, knotter
|
| . . |
15551R1
|
[2] |
BOLT,3/8"-16 x 1", G2, Full Thd
|
IH
plow 3/8 x 1 Superseded by part number: 419-3616
|
| . . |
17426R1
|
[1] |
BOLT,Hex, 3/8" - 16 x 1", Gr 2
|
IH
mach 3/8 x 1 Superseded by part number: 24840R1
|
| . . |
93-41039
|
[2] |
LOCK WASHER,Ext Tooth, 3/8"
|
CAS
WASHER, 3/8 ext-tooth lock Superseded by part number: 280295
|
| 7. |
662009R3
|
[1] |
ANCHOR
|
IH
Superseded by part number: 662009R4
|
| 8. |
662146R1
|
[1] |
BRACKET
|
IH
hay retainer pivot upper
|
| . . |
17446R1
|
[1] |
BOLT,3/8" - 16 x 1 1/4", Gr 2
|
IH
mach 3/8 x 1-1/4 Superseded by part number: 88011
|
| 9. |
667780R2
|
[1] |
|
P
STRIP, filler breast plate RH
|
| 10. |
667810R11
|
[1] |
NO LONGER SERVICED
|
IH
FRAME W/BUSHINGS, knotter drive Superseded by part number: 667810R21
|
| . . |
17552R1
|
[1] |
BOLT, mach. 5/8 x 2-1/4
|
|
| . . |
17578R1
|
[1] |
BOLT (SPREADER),Hex, 5/8"-11 x 2 1/2", G2
|
IH
BOLT, 5/8 x 2-1/2 hex-hd mach Superseded by part number: 271564
|
| . . |
102639
|
[2] |
NUT,5/8"-11, G5
|
IH
Superseded by part number: 280374
|
| . . |
103325
|
[2] |
LOCK WASHER,5/8"
|
IH
WASHER, LOCK, 5/8" Superseded by part number: 86729275
|
| . . |
17471R1
|
[4] |
BOLT,Hex, 3/8" - 16 x 1 1/2"
|
IH
mach. 3/8 x 1-1/2 Superseded by part number: 179843
|
| 11. |
109461
|
[1] |
LUBE NIPPLE,1/8"-27 x .66 lg
|
IH
NIPPLE, LUBE, 1/8"-27 x .66 lg Superseded by part number: 80710
|
| 12. |
667811R1
|
[2] |
BUSHING
|
IH
trip arm stud
|
| 13. |
662112R1
|
[2] |
SPRING
|
IH
twine retainer
|
| . . |
112620
|
[4] |
RIVET
|
IH
csk-hd 1/4 x 7/16 Superseded by part number: 216378
|
| . . |
14995R1
|
[1] |
BOLT
|
IH
CGE. 3/8 x 3/4 Superseded by part number: 19284R1
|
| 14. |
495412R71
|
[2] |
NO LONGER SERVICED
|
IH
FINGER W/RIVETS, breast plate Superseded by part number: 495412R81
|
| . . |
104168
|
[4] |
RIVET,Csk, 1/4" x 7/8"
|
IH
Superseded by part number: 88929
|
| . . |
104166
|
[4] |
SCREW
|
BER
RIVET, csk hd 1/4 x 5/8
|
| 15. |
495929R2
|
[2] |
WEDGE
|
IH
hay retainer narrow
|
| 16. |
495930R1
|
[1] |
WEDGE
|
IH
hay retainer wide
|
| . . |
15009R1
|
[2] |
CARRIAGE BOLT,Short Sq Nk, 7/16" - 14 x 1", Gr 2
|
IH
BOLT, CARRIAGE, Short NK, 7/16"-14 x 1", G2, Full Thd Superseded by part number: 412-716
|
| . . |
NLS
|
[2] |
NO LONGER SERVICED
|
BAS
7/16
|
| . . |
103322
|
[2] |
LOCK WASHER,7/16"
|
IH
WASHER, LOCK, 7/16" Superseded by part number: 81547
|
| 17. |
668974R1
|
[2] |
REINFORCEMENT
|
IH
STRIP, base plate wear, see Note A Superseded by part number: 204017C92
|
| . . |
113225
|
[4] |
RIVET,Csk, 3/16" x 9/16"
|
CAS
3/16 x 9/16 90 deg csk-hd
|
| 18. |
668975R12
|
[2] |
GUIDE
|
IH
FINGER ASSY, breast plate, see Note A Superseded by part number: 204631C91
|
| . . |
17064R1
|
[2] |
LOCK PIN,1/8" x 5/8", Slotted
|
IH
Pin, 1/8" x 5/8", Slotted Superseded by part number: 20948R1
|
| 19. |
87414
|
[1] |
LUBE NIPPLE,1/4" - 28
|
NH
FITTING, 1/4-28 str self tap lub
|
