| 1. |
618029R1
|
[2] |
BEARING
|
CAS
FLANGE, left crank bearing Superseded by part number: 619333R1
|
| 2. |
664597R91
|
[1] |
BALL BEARING,1.5005" ID x 90 mm OD x 1.625"
|
IH
ASSY, crank left Superseded by part number: 47577202
|
| 3. |
664598R11
|
[1] |
COLLAR
|
IH
crank left brg
|
| 4. |
663151R1
|
[1] |
|
P
SPROCKET, pickup drive
|
| . . |
Q55
|
[1] |
KEY,3/8" Sq x 2", Par
|
IH
3/8 x 2 sq parallel
|
| 5. |
663411R1
|
[1] |
|
P
GUSSET, left crank bearing support
|
| 6. |
663487R2
|
[1] |
|
P
SUPPORT, left crank bearing
|
| 7. |
495919R2
|
[1] |
|
P
WASHER, thrust
|
| . . |
495949R1
|
[2] |
|
P
BOLT, 3/8-24 x 1 hex-hd special
|
| 8. |
663259R93
|
[1] |
|
P
SUPPORT ASSY, plunger Pitman
|
| . . |
555301R1
|
[4] |
BOLT,Hex, 5/8" - 11 x 1 3/8", Gr 8
|
IH
SCREW, 5/8-11 x 1-3/8 hex-hd cap Superseded by part number: 26-1022
|
| 9. |
663399R1
|
[1] |
AXLE PIN
|
IH
PIN, plunger
|
| . . |
657196R1
|
[1] |
PIN
|
IH
1/4 x 2 roll spring Superseded by part number: 86624088
|
| 10. |
663156R1
|
[1] |
BEARING
|
IH
Pitman, rear
|
| 11. |
663218R91
|
[1] |
|
P
PITMAN ASSY, plunger
|
| 12. |
663160R21
|
[1] |
|
P
BEARING W/CAP, Pitman front
|
| 13. |
109461
|
[1] |
LUBE NIPPLE,1/8"-27 x .66 lg
|
IH
NIPPLE, LUBE, , PTF 1/8"-27 x .66 lg Superseded by part number: 80710
|
| 14. |
663427R1
|
[2] |
BEARING LINER,3" OD x 4.04"
|
IH
Pitman box
|
| 15. |
663493R93
|
[1] |
|
P
CRANKSHAFT ASSY, plunger
|
| 16. |
273350
|
[1] |
PANEL
|
PA
FITTING, 1/8-27 PTF str special short
|
| 17. |
219320
|
[1] |
|
P
TUBE, plunger lubrication, replaces 665729R1 Nipple, 1/8" NPT x 12"
|
| 18. |
106649
|
[1] |
ELBOW,45 Degree, 1/8" NPT Street
|
IH
1/8 x 45 deg street
|
| . . |
665728R1
|
[4] |
SEAL
|
IH
SEAL, plunger crank Neoprene
|
