凯斯零件查询(57) - INTERNATIONAL HARVESTER RECTANGULAR BALER (1/57-12/72) (A-15) - PLUNGER Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
899 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
663141R1
|
[1] |
|
P
RUNNER, plunger adjustment
|
| 2. |
663396R1
|
[1] |
|
P
BOLT, plunger adjustment
|
| 3. |
663140R1
|
[1] |
|
P
SLIDE, plunger adjustment
|
| 4. |
663400R1
|
[1] |
RUNNER
|
IH
plunger left
|
| 5. |
665188R92
|
[1] |
|
P
PLUNGER ASSY, see Note A
|
| 5. |
663197R93
|
[1] |
|
P
PLUNGER ASSY, see Note B
|
| 6. |
663408R1
|
[1] |
BLOCK
|
IH
plunger upper left
|
| 7. |
663464R2
|
[1] |
BLOCK
|
IH
plunger upper center
|
| 8. |
663407R2
|
[1] |
BLOCK
|
IH
plunger upper right
|
| 9. |
663216R1
|
[4] |
|
P
RUNNER, upper & lower plunger thrust
|
| . . |
104166
|
[8] |
SCREW
|
BER
RIVET, 1/4 x 5/8 csk-hd solid
|
| 10. |
663418R2
|
[2] |
ANGLE
|
IH
plunger runner right
|
| 11. |
663354R1
|
[1] |
KNIFE ASSY
|
IH
KNIFE, hay
|
| 12. |
663728R1
|
[3] |
BOLT (SPREADER)
|
IH
BOLT, hay knife
|
| 13. |
663727R1
|
[1] |
|
P
HOLDER, hay knife
|
| . . |
18494R1
|
[2] |
BOLT,Hex, 3/8" - 16 x 1", Gr 2
|
IH
3/8-16 x 1 C-Z hex-hd mach Superseded by part number: 424-616
|
| . . |
120382
|
[2] |
LOCK WASHER,Helical Spring, 3/8"
|
IH
WASHER, LOCK, 3/8" Superseded by part number: 80680
|
| 14. |
664338R1
|
[1] |
STRIPPER
|
IH
SCRAPER, plunger guide front
|
| 14. |
664339R1
|
[1] |
|
P
SCRAPER, plunger guide rear
|
