凯斯零件查询(57) - INTERNATIONAL HARVESTER RECTANGULAR BALER (1/57-12/72) (A-26) - PICKUP WHEEL, RUBBER, WHEN ORDERED Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
557 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
669006R1
|
[2] |
BUSHING
|
IH
BEARING, pickup wheel
|
| 2. |
669005R1
|
[1] |
TYRE/TIRE
|
IH
TIRE, pickup wheel semi-pneumatic
|
| 3. |
669004R91
|
[1] |
WHEEL
|
IH
ASSY, pickup Superseded by part number: ZA400214
|
| 4. |
125617
|
[1] |
LUBE NIPPLE,3/16" x .61 lg, Drive
|
IH
FITTING, .191 str drive type lub, used with Ohio Rubber Co. and Geneva Wheel Co. only Superseded by part number: 219-13
|
| 4. |
20691R1
|
[1] |
FITTING,3/16" x .47" lg, Drive
|
IH
.191 str drive type lub, used with Dico Wheel Co. only Superseded by part number: 219-411
|
| 5. |
669003R91
|
[1] |
WHEEL
|
IH
W/SEMI-PNEUMATIC TIRE, pickup Superseded by part number: ZA400214
|
| 6. |
669020R91
|
[1] |
|
P
BRACKET ASSY, pickup wheel
|
| . . |
18795R1
|
[2] |
BOLT,Hex, 7/16"-14 x 1 1/4", G2
|
IH
7/16-14 x 1-1/4 cd-pltd hex-hd mach Superseded by part number: 179860
|
| . . |
187988
|
[1] |
COTTER PIN,3/16" x 1 1/4"
|
IH
PIN, SPLIT (COTTER), 3/16" x 1 1/4" Superseded by part number: 87398
|
| . . |
120383
|
[2] |
LOCK WASHER,Helical Spring, 7/16"
|
IH
WASHER, LOCK, 7/16" Superseded by part number: 81547
|
| . . |
607891R1
|
[1] |
WASHER
|
IH
15/32 x 1 x 16 ga C-Z Superseded by part number: 495-81158
|
| . . |
178375
|
[1] |
WASHER, 25/32 x 1-1/4 x 16 ga C-Z
|
|
| . . |
131017
|
[1] |
WASHER
|
IH
13/16 x 1-1/2 x 10 ga C-Z Superseded by part number: 495-11081, 495-11081, NLS
|
