凯斯零件查询(57) - INTERNATIONAL HARVESTER RECTANGULAR BALER (1/57-12/72) (A-30) - TWINE NEEDLES AND NEEDLE PITMAN Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
765 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
663581R92
|
[1] |
|
P
PIPE ASSY, needle tie
|
| 2. |
127786
|
[1] |
ADJUSTABLE CLEVIS,5/16"-18 x 4 15/16"
|
IH
CLEVIS, 5/8-18 x 4-15/16 hv adj rod end Superseded by part number: 213-2110
|
| . . |
137185
|
[1] |
COTTER PIN,1/8" x 1"
|
IH
PIN, SPLIT (COTTER), 1/8" x 1" Superseded by part number: 80755
|
| . . |
22754R1
|
[1] |
CLEVIS PIN,5/8" x 1.844"
|
IH
PIN, CLEVIS, , Rod end 5/8" x 1.844"
|
| 3. |
662282R1
|
[1] |
PITMAN
|
CAS
needle, 004394 and below Superseded by part number: 1980553C1
|
| . . |
350515R1
|
[1] |
WASHER
|
IH
21/32 x 1 x 16 ga Superseded by part number: 495-81176
|
| 4. |
271284
|
[2] |
YOKE
|
NNA
1/8-27 65 deg angle lub Superseded by part number: 219-40, 219-40, NLS
|
| 5. |
662029R1
|
[2] |
PIVOT
|
IH
BEARING, needle pivot
|
| 6. |
663718R1
|
[1] |
|
P
CLIP, bale counter
|
| 7. |
11792P
|
[2] |
HOLDER
|
IH
twine guide
|
| 8. |
668723R1
|
[2] |
|
P
PIVOT, needle
|
| . . |
664646R1
|
[4] |
LOCK NUT,7/16"-14, GB
|
IH
NUT, 7/16-14 lock Superseded by part number: 280980
|
| . . |
F18476
|
[4] |
WASHER
|
IH
1-9/32 x 1-3/4 x 16 ga, (or as required) Superseded by part number: 87613234
|
| 9. |
663187R2
|
[1] |
NEEDLE BEARING CAGE
|
IH
NEEDLE, left twine
|
| . . |
PO10535
|
[2] |
WASHER
|
IH
17/32 x 1-1/4 x 11 ga Superseded by part number: 495-81287
|
| 10. |
11833PB
|
[4] |
GUIDE
|
IH
twine Superseded by part number: 1344948C1
|
| 11. |
665719R91
|
[1] |
|
P
NEEDLE, right twine
|
| . . |
179887
|
[4] |
CABLE
|
NNA
Superseded by part number: 413-828
|
| . . |
103323
|
[4] |
LOCK WASHER,1/2"
|
IH
WASHER, LOCK, 1/2" Superseded by part number: 87326976
|
| . . |
455150R1
|
[4] |
WASHER
|
IH
17/32 x 1-1/4 x 1/4 Superseded by part number: 87393626
|
| 12. |
668944R1
|
[1] |
|
P
BAND, twine guide
|
| 13. |
201667C91
|
[1] |
PITMAN
|
IH
ROD ASSY, needle Pitman, 004395 and up
|
| . . |
121358
|
[1] |
YOKE
|
NNA
5/8-18 znd hex. Superseded by part number: 425-1110, 425-1110, NLS
|
| . . |
21796R1
|
[2] |
WASHER
|
IH
21/32 x 1 x 16 ga C-Z Superseded by part number: 495-81176
|
| 14. |
201669C1
|
[1] |
PIN
|
IH
needle Pitman, 004395 and up Superseded by part number: 201667C91
|
