凯斯零件查询(57) - INTERNATIONAL HARVESTER RECTANGULAR BALER (1/57-12/72) (A-30[A]) - WIRE NEEDLES AND NEEDLE PITMAN Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
406 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
662032R2
|
[1] |
CONNECTOR, ELEC
|
IH
CONNECTOR, needle Pitman
|
| . . |
663047R2
|
[1] |
PIN
|
IH
3/4 x 2-5/32 rod end
|
| 2. |
663430R1
|
[1] |
|
P
ROD, needle Pitman
|
| . . |
218443
|
[1] |
NUT
|
IH
3/4-10 hex. jam Superseded by part number: 86632557
|
| 3. |
668724R1
|
[2] |
|
P
PIVOT, needle
|
| . . |
664646R1
|
[4] |
LOCK NUT,7/16"-14, GB
|
IH
NUT, 7/16-14 lock Superseded by part number: 280980
|
| . . |
F18476
|
[4] |
WASHER
|
IH
1-9/32 x 1-3/4 x 16 ga (or as required) Superseded by part number: 87613234
|
| 4. |
219-8
|
[2] |
LUBE NIPPLE,1/4" - 28 NPTF
|
CAS
NIPPLE, LUBE, , straight 1/4"-28 NPT x .54" lg Superseded by part number: 87414
|
| 5. |
667415R1
|
[2] |
BUSHING
|
IH
needle sheave
|
| . . |
46-413
|
[2] |
RIVET,Csk, 1/4" x 3/4"
|
CAS
1/4 x 13/16 90 deg csk-hd
|
| 6. |
667412R1
|
[2] |
ROLL
|
IH
SHEAVE, needle
|
| 7. |
667414R1
|
[2] |
BUSHING
|
IH
needle tip
|
| . . |
102688
|
[2] |
RIVET,Csk, 3/16" x 13/16"
|
IH
3/16 x 13/16 csk-hd
|
| 8. |
667413R1
|
[2] |
SPACER
|
IH
PIECE, needle tip wearing
|
| 9. |
667437R11
|
[2] |
NEEDLE BEARING CAGE
|
IH
NEEDLE ASSY, wire
|
| . . |
413-828
|
[4] |
BOLT,Hex, 1/2" - 13 x 1-3/4", Gr 5
|
CAS
Superseded by part number: 9707516, 72187217
|
| . . |
103323
|
[4] |
LOCK WASHER,1/2"
|
IH
WASHER, LOCK, 1/2" Superseded by part number: 87326976
|
| . . |
20601R1
|
[4] |
WASHER
|
IH
17/32 x 1-1/4 x 11 ga C-Z Superseded by part number: 495-81287
|
| 10. |
664537R91
|
[1] |
|
P
PIPE ASSY, needle tie
|
