| 1. |
666658R1
|
[1] |
|
P
PLATE, knotter base
|
| 2. |
666659R1
|
[3] |
|
P
RETAINER, top hay
|
| . . |
Q3534
|
[3] |
HEADED PIN,9.53mm OD x 38.1mm L
|
IH
PIN, 3/8 x 1-1/2 std-hd
|
| 3. |
665192R1
|
[3] |
SPRING
|
IH
top hay retainer
|
| 4. |
663578R91
|
[3] |
|
P
BRACKET ASSY, top hay retainer
|
| 5. |
495930R1
|
[1] |
WEDGE
|
IH
hay retainer broad
|
| . . |
18695R1
|
[2] |
CARRIAGE BOLT,Short Sq Nk, 7/16" - 14 x 1 1/4", Gr 2
|
IH
BOLT, 7/16-14 x 1-1/4 znd short sq-nk crg
|
| . . |
NLS
|
[2] |
NO LONGER SERVICED
|
BAS
NUT, 7/16-14 znd hex.
|
| . . |
120383
|
[2] |
LOCK WASHER,Helical Spring, 7/16"
|
IH
WASHER, LOCK, 7/16" Superseded by part number: 81547
|
| 6. |
495412R91
|
[2] |
FINGER W/RIVETS, breast plate
|
|
| . . |
104168
|
[4] |
RIVET,Csk, 1/4" x 7/8"
|
IH
Superseded by part number: 88929
|
| 7. |
662112R1
|
[2] |
SPRING
|
IH
twine retainer
|
| . . |
104166
|
[4] |
SCREW
|
BER
RIVET, 1/4 x 5/8 csk-hd
|
| 8. |
87414
|
[1] |
LUBE NIPPLE,1/4" - 28
|
NH
FITTING, 1/4-28 self tap. str lub
|
| 9. |
495929R2
|
[2] |
WEDGE
|
IH
hay retainer upper
|
| . . |
18684R1
|
[4] |
BOLT,Sht Sq Nk, 3/8" - 16 x 1 1/4", Gr 2
|
IH
3/8-16 x 1-1/4 znd short sq-nk crg Superseded by part number: 550796R1
|
| . . |
120377
|
[4] |
NUT,3/8" - 16, Gr 5
|
IH
Superseded by part number: 280136
|
| . . |
120382
|
[4] |
LOCK WASHER,Helical Spring, 3/8"
|
IH
WASHER, LOCK, 3/8" Superseded by part number: 80680
|
| 10. |
668974R1
|
[2] |
REINFORCEMENT
|
IH
STRIP, base plate wear, see Note A Superseded by part number: 204017C92
|
| . . |
113225
|
[4] |
RIVET,Csk, 3/16" x 9/16"
|
CAS
3/16 x 9/16 90 deg csk-hd
|
| 11. |
668975R12
|
[2] |
GUIDE
|
IH
FINGER ASSY, breast plate, see Note A Superseded by part number: 204631C91
|
| . . |
17064R1
|
[2] |
LOCK PIN,1/8" x 5/8", Slotted
|
IH
Pin, 1/8" x 5/8", Slotted Superseded by part number: 20948R1
|
