| 1. |
663492R4
|
[1] |
REINFORCEMENT, bale chamber left
|
|
| 2. |
663578R91
|
[2] |
|
P
BRACKET ASSY, top hay retainer
|
| 3. |
665192R1
|
[2] |
SPRING
|
IH
top hay retainer
|
| 4. |
663158R1
|
[2] |
|
P
RETAINER, top hay
|
| . . |
Q3534
|
[2] |
HEADED PIN,9.53mm OD x 38.1mm L
|
IH
PIN, 3/8 x 1-1/2 std-hd
|
| 5. |
656956R1
|
[2] |
STUD
|
IH
stripper pivot front
|
| . . |
28407K
|
[2] |
WASHER
|
IH
17/32 x 1-1/4 x 22 ga
|
| . . |
660466R1
|
[2] |
WASHER
|
IH
stripper front pivot stud
|
| 6. |
656945R1
|
[2] |
BEARING
|
IH
BUSHING, stripper pivot
|
| 7. |
667235R1
|
[4] |
SPACER
|
IH
guide plate
|
| 8. |
667234R1
|
[2] |
PLATE
|
IH
stripper finger guide
|
| 9. |
116537
|
[1] |
SPACER
|
PA
CLEVIS, 7/16-20 x 2-1/2 short adj rod end
|
| . . |
658714R1
|
[1] |
PIN, stripper clevis
|
|
| 10. |
658742R1
|
[1] |
CLEVIS COUPLING
|
IH
CLIP, stripper clevis pin
|
| 11. |
656930R2
|
[1] |
ROD
|
IH
stripper actuating
|
| 12. |
667236R2
|
[1] |
ROD, 3/8-24 x 1-1/8 ball
|
|
| 13. |
656932R1
|
[1] |
ROD
|
IH
wire stripper connecting
|
| 14. |
667237R91
|
[1] |
JOINT
|
IH
3/8-24 x 1-1/8 ball LH thd
|
| 15. |
659567R91
|
[1] |
JOINT TURNING
|
IH
JOINT, 7/16-20 x 5/8 stripper connecting rod ball
|
| . . |
667596R1
|
[1] |
NUT
|
IH
WASHER, 7/16 med lock
|
| 16. |
663364R1
|
[2] |
BUSHING
|
IH
packer crank Superseded by part number: 667844R1
|
| 17. |
109461
|
[1] |
LUBE NIPPLE,1/8"-27 x .66 lg
|
IH
NIPPLE, LUBE, , PTF 1/8"-27 x .66 lg Superseded by part number: 80710
|
| 18. |
663157R21
|
[1] |
|
P
FRAME, w/bushings, knotter & twister drive
|
| 19. |
657115R1
|
[2] |
FINGER
|
IH
INSERT, twister frame, 4149N and below
|
| 20. |
495930R1
|
[2] |
WEDGE
|
IH
hay retainer broad
|
| 21. |
663159R3
|
[1] |
|
P
PLATE, wire twister base
|
| 22. |
667230R91
|
[2] |
FINGER
|
IH
ASSY, stripper
|
| . . |
Q1597
|
[6] |
WASHER
|
IH
13/32 x 3/4 x 16 ga Superseded by part number: 86632580
|
| 23. |
667233R1
|
[2] |
ANCHOR
|
IH
stripper finger
|
| . . |
156513
|
[4] |
SCREW,Cross Flat Hd, 3/8" - 16 x 1/2"
|
IH
3/8-16 x 1/2 cd-pltd cr-rec-hd mach
|
| . . |
575808R1
|
[4] |
WASHER
|
IH
19/32 x 1 x 16 ga
|
| 24. |
668571R1
|
[1] |
|
P
EXTENSION, reinforcement plate
|
| 25. |
671121R1
|
[1] |
DEFLECTOR
|
IH
wire twist LH, 004150 and up
|
| 26. |
671122R1
|
[1] |
DEFLECTOR
|
IH
wire twist RH, 004150 and up
|
| . . |
20717R1
|
[1] |
BOLT, 7/16 x 7/8 znd hex-hd mach
|
|
| . . |
120383
|
[1] |
LOCK WASHER,Helical Spring, 7/16"
|
IH
WASHER, LOCK, 7/16" Superseded by part number: 81547
|
| . . |
22196R1
|
[1] |
WASHER
|
IH
15/32 x 7/8 x 16 ga C-Z Superseded by part number: 87019792
|
| 27. |
674724R1
|
[2] |
INSERT
|
IH
twister frame, 004150 and up
|
| . . |
19020R1
|
[4] |
PLOW BOLT,#3, 3/8" - 16 x 1 1/4", Gr 2
|
IH
BOLT, 3/8 x 1-1/4 znd No. 3 plow Superseded by part number: 19031R1
|
| . . |
120377
|
[4] |
NUT,3/8" - 16, Gr 5
|
IH
Superseded by part number: 280136
|
| . . |
120382
|
[4] |
LOCK WASHER,Helical Spring, 3/8"
|
IH
WASHER, LOCK, 3/8" Superseded by part number: 80680
|
