凯斯零件查询(57) - INTERNATIONAL HARVESTER RECTANGULAR BALER (1/57-12/72) (A-50) - POWER TAKE-OFF ATTACHMENT, PLUNGER CRANK AND PULLEY SHIELDS Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
574 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
668652R91
|
[1] |
|
P
SHIELD ASSY, plunger crank front
|
| 2. |
668657R1
|
[1] |
|
P
SUPPORT, plunger crank shield
|
| 3. |
668658R91
|
[1] |
|
P
SHIELD ASSY, plunger crank rear
|
| 4. |
663189R1
|
[1] |
|
P
MOUNT, engine front
|
| 5. |
668695R91
|
[1] |
|
P
SHIELD ASSY, pulley
|
| . . |
Q5097
|
[2] |
WASHER
|
IH
15/32 x 1-1/4 x 16 ga Superseded by part number: 106263
|
| 6. |
663599R1
|
[1] |
|
P
BRACKET, pulley shield
|
| . . |
2751405R1
|
[1] |
PRODUCT GRAPHICS, IH trade mark, Decal
|
|
| . . |
2751271R1
|
[1] |
PRODUCT GRAPHIC
|
IH
S, International, Decal on left side of plunger crank shield
|
