| 1. |
271929R21
|
[1] |
|
P
BRACE ASSY, radiator support
|
| . . |
179816
|
[1] |
BOLT,Hex, 5/16" - 18 x 3/4", Gr 5
|
IH
Superseded by part number: 87872
|
| . . |
179849
|
[1] |
BOLT,Hex, 3/8" - 16 x 2 1/2", Gr 5
|
IH
Superseded by part number: 87936
|
| . . |
181425
|
[2] |
BOLT,Hex, 1/2" - 20 x 3/4"
|
IH
SCREW, 1/2-20 x 3/4 hex-hd Superseded by part number: 114-415
|
| . . |
103320
|
[1] |
LOCK WASHER,5/16"
|
IH
WASHER, LOCK, 5/16" Superseded by part number: 322358, 83990583
|
| . . |
103323
|
[2] |
LOCK WASHER,1/2"
|
IH
WASHER, LOCK, 1/2" Superseded by part number: 87326976
|
| 2. |
353586R91
|
[1] |
|
P
HOUSING ASSY, fan
|
| . . |
425-115
|
[4] |
NUT,5/16"-24, G5
|
CAS
5/16-24 hex. Superseded by part number: 86629539
|
| . . |
NLS
|
[4] |
NO LONGER SERVICED
|
BAS
SCREW, 5/16-24 x 4 hex-hd cap
|
| 3. |
274088R91
|
[4] |
HOSE CLAMP,2.25/3.13 Type F Worm
|
IH
CLAMP, radiator hose Superseded by part number: 214-1442
|
| 4. |
271767R2
|
[1] |
|
P
HOSE, radiator inlet
|
| 5. |
276755R92
|
[1] |
|
P
RADIATOR ASSY
|
| . . |
103867
|
[1] |
PLUG
|
IH
radiator drain
|
| . . |
352632R1
|
[2] |
BOLT,Sq Nk, 7/16" - 20 x 1 1/8"
|
IH
radiator support
|
| . . |
271505
|
[2] |
BODY
|
NNA
7/16-20 hex. Superseded by part number: 425-117, 425-117, NLS
|
| . . |
103322
|
[2] |
LOCK WASHER,7/16"
|
IH
WASHER, LOCK, 7/16" Superseded by part number: 81547
|
| 6. |
393229R91
|
[1] |
CAP
|
IH
radiator pressure
|
| 7. |
271928R1
|
[4] |
GROMMET
|
IH
MOUNT, radiator support rubber shock Superseded by part number: V56194
|
| . . |
181377
|
[4] |
BOLT,Hex, 3/8" - 24 x 1 3/4", Gr 5
|
IH
SCREW, 3/8-24 x 1-3/4 hex-hd cap Superseded by part number: 88117
|
| . . |
PO105341/2
|
[4] |
WASHER, 15/32 x 1-1/2 x 11 ga
|
|
| 8. |
271925R1
|
[1] |
|
P
SUPPORT, radiator, LH
|
| 9. |
272183R1
|
[2] |
|
P
BRACE, radiator cross
|
| 10. |
271926R1
|
[1] |
|
P
SUPPORT, radiator, RH
|
| 11. |
277149R1
|
[1] |
|
P
HOSE, radiator outlet
|
| . . |
103374
|
[1] |
COTTER PIN,3/32" x 1"
|
IH
Pin, Split (Cotter), 3/32" x 1" Superseded by part number: 280251
|
| . . |
95-11041
|
[1] |
WASHER,3/8"
|
CAS
13/32 x 13/16 x 16 ga Superseded by part number: 87016
|
