| 1. |
359192R1
|
[1] |
|
P
ROD, governor control, front
|
| . . |
114492
|
[1] |
JAM NUT,Jam, 1/4"-28, G5
|
IH
1/4-28 hex. jam Superseded by part number: 86976064
|
| . . |
432-68
|
[1] |
COTTER PIN,3/32" x 1/2"
|
CAS
Pin, Split (Cotter), 3/32" x 1/2" Superseded by part number: 88788
|
| . . |
95-11028
|
[1] |
WASHER,1/4"
|
CAS
9/32 x 5/8 x 16 ga
|
| 2. |
104036
|
[1] |
ADJUSTABLE CLEVIS,1/4"-28 x 2"
|
IH
CLEVIS, 1/4-28 adj rod end Superseded by part number: 213-114
|
| . . |
103494
|
[1] |
ADJUSTABLE CLEVIS,1/4" x .770"
|
IH
PIN, 1/4 x 51/64 rod end Superseded by part number: 141-52
|
| . . |
107761
|
[1] |
COTTER PIN,1/16" x 5/8"
|
IH
Pin, Split (Cotter), 1/16" x 5/8" Superseded by part number: 280224
|
| 3. |
359191R1
|
[1] |
|
P
LEVER, governor control
|
| . . |
109084
|
[1] |
NUT,1/4"-20, G5
|
IH
Superseded by part number: 7770
|
| . . |
179799
|
[1] |
BOLT,Hex, 1/4" - 20 x 1 1/4", Gr 5
|
IH
Superseded by part number: 87716
|
| . . |
103319
|
[1] |
LOCK WASHER,1/4"
|
IH
WASHER, LOCK, 1/4" Superseded by part number: 92-11025
|
| 4. |
352026R2
|
[1] |
SPRING
|
IH
governor control rod
|
| 5. |
275105R11
|
[1] |
|
P
PANEL ASSEMBLY, control
|
| . . |
17414R1
|
[2] |
SCREW, 1/2-13 x 3/4 hex-hd cap
|
|
| . . |
103323
|
[2] |
LOCK WASHER,1/2"
|
IH
WASHER, LOCK, 1/2" Superseded by part number: 87326976
|
| 6. |
110731
|
[4] |
KEY
|
IH
3/32 x 5/8 Woodruff
|
| 7. |
359188R91
|
[1] |
|
P
HANDLE ASSY, governor control
|
| . . |
103374
|
[1] |
COTTER PIN,3/32" x 1"
|
IH
Pin, Split (Cotter), 3/32" x 1" Superseded by part number: 280251
|
| . . |
95-11041
|
[1] |
WASHER,3/8"
|
CAS
13/32 x 13/16 x 16 ga Superseded by part number: 87016
|
