凯斯零件查询(57) - INTERNATIONAL HARVESTER RECTANGULAR BALER (1/57-12/72) (A-67) - OIL PRESSURE INDICATOR AND CONNECTIONS Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
495 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
393488R91
|
[1] |
SWITCH
|
IH
INDICATOR ASSY, oil pressure Superseded by part number: 536962R2
|
| 2. |
67869D
|
[1] |
ELBOW,90 Degree x 1/8" NPT x 7/16"-24, Fem
|
IH
7/16-24 90 deg hi-duty tube fitting female pipe
|
| 3. |
19894R1
|
[2] |
DOWEL
|
IH
NUT, nylon insert tube
|
| 4. |
23142D
|
[1] |
|
P
FELT, oil pressure indicator tube clip
|
| 5. |
27385D
|
[1] |
|
P
CLIP, oil pressure indicator tube
|
| 6. |
275106R1
|
[1] |
|
P
TUBE, oil prssure indicator
|
| 7. |
30402D
|
[1] |
ELBOW,90 Degree x 1/8" NPT x 7/16"-24
|
IH
1/4 male pipe
|
