| 1. |
49291D
|
[1] |
V-BELT,0.53" W
|
IH
Generator
|
| 2. |
6812D
|
[1] |
PULLEY
|
CAS
PULLEY, generator
|
| 3. |
60714DA
|
[1] |
SUPPORT
|
IH
BRACE, generator
|
| . . |
280185R1
|
[1] |
SPACER
|
IH
SPACER, generator brace
|
| . . |
179816
|
[2] |
BOLT,Hex, 5/16" - 18 x 3/4", Gr 5
|
IH
BOLT, Hex, 5/16"-18 x 3/4", G5, Full Thd Superseded by part number: 87872
|
| . . |
103320
|
[2] |
LOCK WASHER,5/16"
|
IH
WASHER, LOCK, 5/16" Superseded by part number: 322358, 83990583
|
| 4. |
1100501
|
[1] |
|
P
SPARE PART GENERATOR ASSY, 354237R91, 6 volt, for components see list of parts under details of generator
|
| 4. |
103821A1R
|
[1] |
REMAN-GENERATOR
|
CAS
Generator 6V
|
| 4. |
103821A1C
|
[1] |
CORE-GENERATOR
|
CAS
Return Part Number
|
| 4. |
87497945R
|
[1] |
REMAN-ALTERNATOR
|
MKT
Kit to convert reman generator 103821R to an alternator. Kit includes: instruction sheet, hardware kit, 12 v. resistor ballast, wire harness, mounting brkt., tension brkt., reman alternator 12 volt 63 amp w/pulley & regulator.
|
| . . |
9635082
|
[1] |
NUT,5/16" - 18, Gr 5
|
NH
NUT, 5/16-18 hex.
|
| . . |
17934R1
|
[1] |
SCREW, 5/16-18 x 7-1/4 hex-hd cap
|
|
| 5. |
274460R11
|
[1] |
|
P
SPARE PART BRACKET ASSY, generator
|
| . . |
17426R1
|
[2] |
BOLT,Hex, 3/8" - 16 x 1", Gr 2
|
IH
SCREW, 3/8-16 x 1 hex-hd cap Superseded by part number: 24840R1
|
| . . |
103321
|
[2] |
LOCK WASHER,3/8"
|
IH
WASHER, LOCK, 3/8" Superseded by part number: 80680
|
| 6. |
1119575
|
[1] |
REGULATOR
|
IH
REGULATOR ASSY, voltage, 376121R91, 6 volt, only serviceable items are cover, 1927980 & gasket, 1953902 Superseded by part number: 121578C1GV
|
| . . |
17403R1
|
[2] |
BOLT,Hex, 1/4" - 20 x 1/2", Gr 2
|
IH
BOLT, 1/4-20 x 1/2 hex-hd mach Superseded by part number: 22704R1
|
| . . |
80682
|
[2] |
LOCK WASHER,1/4"
|
PA
Washer, Lock, 1/4"
|
