| 1. |
1100401
|
[1] |
|
P
GENERATOR ASSY, 319622R91 12 volt, for components see list of parts under details of generator
|
| . . |
121743
|
[2] |
CHAIN,#12 - 24
|
NNA
12-24 C-Z hex. mach screw Superseded by part number: 225-14112
|
| . . |
9635082
|
[1] |
NUT,5/16" - 18, Gr 5
|
NH
5/16-18 hex.
|
| . . |
179818
|
[1] |
BOLT,Hex, 5/16" - 18 x 1", Gr 5
|
IH
Superseded by part number: 9635884
|
| . . |
17934R1
|
[1] |
SCREW, 5/16-18 x 7-1/4 hex-hd cap
|
|
| . . |
492-11012
|
[2] |
LOCK WASHER,#12
|
CAS
Washer, Lock, #12
|
| . . |
103320
|
[2] |
LOCK WASHER,5/16"
|
IH
WASHER, LOCK, 5/16" Superseded by part number: 322358, 83990583
|
| 2. |
391612R1
|
[1] |
|
P
BRACE, generator
|
| . . |
280185R1
|
[1] |
SPACER
|
IH
generator brace
|
| . . |
179816
|
[1] |
BOLT,Hex, 5/16" - 18 x 3/4", Gr 5
|
IH
Superseded by part number: 87872
|
| 3. |
1944437
|
[1] |
FAN
|
IH
generator Superseded by part number: A25449
|
| 4. |
368594R1
|
[1] |
|
P
BAFFLE, generator fan
|
| 5. |
368591R1
|
[1] |
PULLEY
|
IH
generator
|
| 6. |
379629R1
|
[1] |
V-BELT,0.50" W x 28.50" L
|
IH
Generator 0.50" W x 28.50" L
|
| 7. |
274460R11
|
[1] |
|
P
BRACKET ASSY, generator mounting
|
| . . |
17426R1
|
[2] |
BOLT,Hex, 3/8" - 16 x 1", Gr 2
|
IH
SCREW, 3/8-16 x 10 hex-hd cap Superseded by part number: 24840R1
|
| . . |
103321
|
[2] |
LOCK WASHER,3/8"
|
IH
WASHER, LOCK, 3/8" Superseded by part number: 80680
|
| 8. |
1118999
|
[1] |
REGULATOR
|
IH
REGULATOR ASSY, voltage, 376122R91 12 volt, only serviceable items are cover, 1927980 and gasket, 1953202 Superseded by part number: 121577C1GV
|
| . . |
17403R1
|
[2] |
BOLT,Hex, 1/4" - 20 x 1/2", Gr 2
|
IH
SCREW, 1/4-20 x 1/2 hex-hd cap Superseded by part number: 22704R1
|
| . . |
103319
|
[2] |
LOCK WASHER,1/4"
|
IH
WASHER, LOCK, 1/4" Superseded by part number: 92-11025
|
