GENERATOR ASSY, 354237R91, 6 volt
|
| . . |
103821A1R
|
[1] |
REMAN-GENERATOR
|
CAS
Generator 6V
|
| . . |
103821A1C
|
[1] |
CORE-GENERATOR
|
CAS
Return Part Number
|
| . . |
87497945R
|
[1] |
REMAN-ALTERNATOR
|
MKT
Kit to convert reman generator 103821R to an alternator. Kit includes: instruction sheet, hardware kit, 12 v. resistor ballast, wire harness, mounting brkt., tension brkt., reman alternator 12 volt 63 amp w/pulley & regulator.
|
| 1. |
815018
|
[2] |
BOLT, thru
|
|
| 2. |
120368
|
[2] |
NUT,5/16"-24, G5
|
IH
WASHER, thru bolt lock Superseded by part number: 86629539
|
| 3. |
820524
|
[1] |
PLATE, commutator end frame cover
|
|
| . . |
1886496
|
[3] |
SCREW, cover plate
|
|
| . . |
121841
|
[3] |
LOCK WASHER,#8
|
IH
WASHER, LOCK, #8 Superseded by part number: 87812
|
| 4. |
817220
|
[1] |
GASKET
|
IH
cover plate
|
| 5. |
1880635
|
[1] |
OILER
|
CAS
ASSY, commutator end frame Superseded by part number: 113702
|
| . . |
804076
|
[1] |
WICK
|
IH
oiler Superseded by part number: 1947350
|
| 6. |
1913564
|
[1] |
FRAME
|
IH
ASSY, commutator end, composed of (1) bushing (NSS), (1) frame (NSS), (1) oiler 1880635, (1) pin 809062, (1) plug 1911097, (1) wick 804076 Superseded by part number: 1853830
|
| 7. |
1913737
|
[1] |
|
P
PLATE ASSY, brush
|
| 8. |
1850760
|
[2] |
SPRING, main brush
|
|
| 9. |
1858754
|
[1] |
STUD
|
IH
POLE ASSY, armature terminal
|
| . . |
1885090
|
[1] |
BUSHING
|
CAS
terminal stud insulating Superseded by part number: 1858749
|
| . . |
225-14112
|
[2] |
NUT,#12-24
|
CAS
No. 12-24 cd or zn-pltd hex. Superseded by part number: 86512084
|
| . . |
1858751
|
[1] |
STUD
|
IH
armature terminal Superseded by part number: A40702
|
| . . |
1881409
|
[1] |
WASHER
|
IH
terminal stud Superseded by part number: 195-102
|
| . . |
1858753
|
[1] |
WASHER
|
IH
terminal stud insulating
|
| . . |
1904661
|
[2] |
LOCK WASHER
|
IH
WASHER, terminal stud lock Superseded by part number: 120380
|
| 10. |
1850767
|
[1] |
SPRING
|
IH
third brush Superseded by part number: 1946798
|
| 11. |
1850759
|
[3] |
|
P
HOLDER, brush
|
| . . |
1857412
|
[3] |
WASHER, brush holder space
|
|
| 12. |
1933144
|
[1] |
PACKAGE
|
IH
BRUSH PACKAGE Superseded by part number: 1906984, 1857963
|
| . . |
132688
|
[3] |
SCREW,Sl Rnd Hd, #6 - 32 x 1/4"
|
IH
No. 6-32 x 1/4 cd-pltd slt-rd-hd mach Superseded by part number: 281043
|
| . . |
192-15
|
[3] |
LOCK WASHER,Helical Spring, #6, 0.145" ID, CST, ZND
|
CAS
WASHER, brush screw attaching Superseded by part number: 87276
|
| 13. |
1872638
|
[1] |
BAND
|
IH
W/NUT AND SCREW, cover
|
| . . |
120614
|
[1] |
NUT,Hex, #10 - 32
|
IH
NUT, #10-32 Superseded by part number: 87825
|
| . . |
132926
|
[1] |
SCREW,Sl Rnd Hd, #10 - 32 x 1/4"
|
IH
No. 10-32 x 1-1/4 cd-pltd slt-rd-hd mach
|
| 14. |
809062
|
[1] |
|
P
PIN, commutator end frame dowel
|
| 16. |
809593
|
[1] |
PIN
|
IH
drive end frame dowel
|
| 17. |
1913560
|
[1] |
ARMATURE
|
IH
Superseded by part number: 1947802
|
| 18. |
124545
|
[1] |
WOODRUFF KEY,#5, 1/8" x 5/8", HT
|
IH
Superseded by part number: 87034805
|
| 19. |
809945
|
[1] |
BUSHING
|
IH
WASHER, drive end space
|
| 20. |
1913554
|
[1] |
|
P
COIL ASSY, field
|
| 22. |
1914491
|
[2] |
INSULATOR, field coil
|
|
| 23. |
1914618
|
[2] |
SHOE, pole
|
|
| . . |
1843646
|
[2] |
SCREW
|
IH
pole shoe Superseded by part number: 1968396
|
| 24. |
1911263
|
[1] |
LARGE PLATE
|
IH
PLATE, ball bearing retainer Superseded by part number: A52397
|
| . . |
1914580
|
[3] |
SCREW
|
IH
plate retainer Superseded by part number: A41959
|
| . . |
1880781
|
[3] |
WASHER
|
CAS
plate retainer screw Superseded by part number: 178383
|
| 25. |
1912008
|
[1] |
FELT
|
IH
GASKET, retainer plate Superseded by part number: R16170
|
| 26. |
954378
|
[1] |
BALL BEARING
|
IH
BEARING, drive end ball Superseded by part number: 3064411R91
|
| 27. |
819104
|
[1] |
WASHER
|
IH
RETAINER, drive end felt washer Superseded by part number: R16169
|
| 28. |
809961
|
[1] |
FELT
|
IH
WASHER, drive end felt
|
| 29. |
817224
|
[1] |
SPACER, pulley
|
|
| 30. |
1873830
|
[1] |
FRAME ASSY, drive end
|
|
| 31. |
1880641
|
[1] |
OILER
|
CAS
ASSY, drive end frame Superseded by part number: 125609
|
| 32. |
804000
|
[1] |
WASHER, drive end shaft nut
|
|
| 33. |
1914308
|
[1] |
|
P
NUT, drive end shaft
|
