1100401
|
[1] |
|
P
GENERATOR ASSY, 319622R91, 12 VOLT
|
| 1. |
1928952
|
[1] |
ARMATURE
|
IH
Superseded by part number: A48390
|
| 2. |
1914618
|
[2] |
SHOE, pole
|
|
| 3. |
1843646
|
[2] |
SCREW
|
IH
pole shoe Superseded by part number: 1968396
|
| 4. |
1921369
|
[1] |
STUD
|
CAS
terminal armature
|
| . . |
225-14112
|
[1] |
NUT,#12-24
|
CAS
12-24 C-Z hex. mach screw Superseded by part number: 86512084
|
| 5. |
1885090
|
[1] |
BUSHING
|
CAS
field terminal insulating Superseded by part number: 1858749
|
| 6. |
1921362
|
[1] |
BUSHING
|
IH
armature terminal insulating Superseded by part number: R16147
|
| 7. |
1858753
|
[1] |
WASHER
|
IH
terminal stud insulating
|
| 8. |
1881409
|
[2] |
WASHER
|
IH
terminal stud Superseded by part number: 195-102
|
| 9. |
1904661
|
[2] |
LOCK WASHER
|
IH
WASHER, field terminal stud lock Superseded by part number: 120380
|
| 10. |
1923625
|
[1] |
COIL ASSY.
|
IH
COIL ASSY, field Superseded by part number: R16149
|
| 11. |
1921860
|
[1] |
STUD
|
CAS
terminal field Superseded by part number: 1858749
|
| 12. |
1914491
|
[2] |
INSULATOR, field coil
|
|
| 13. |
1951512
|
[1] |
HOUSING
|
IH
FRAME ASSY, commutator end, composed of (1) dowel 809062, (1) frame (NSS), (1) oiler 1880635, (1) retainer 1947697, (1) seal 1945697, (1) wick 1947350 Superseded by part number: A40679
|
| 14. |
1947350
|
[1] |
WICK
|
IH
commuator end oil Superseded by part number: A41417
|
| 15. |
1945697
|
[1] |
GUARD ASSY.
|
IH
SEAL, commutator end oil
|
| 16. |
1953202
|
[1] |
RETAINER, commutor end oil seal
|
|
| 17. |
1880635
|
[1] |
OILER
|
CAS
ASSY, commutator end Superseded by part number: 113702
|
| 18. |
1932506
|
[2] |
BRUSH, COMMUTATOR
|
IH
BRUSH Superseded by part number: R15088
|
| 19. |
1922288
|
[1] |
HOLDER
|
CAS
PACKAGE, ground brush holder
|
| . . |
132979
|
[1] |
|
P
SCREW, No. 12-24 x 5/8 C-Z slt-rd-hd mach
|
| . . |
131184
|
[1] |
CONNECTING LINK
|
PA
WASHER, No. 12 C-Z med lock
|
| 20. |
1922289
|
[1] |
HOLDER
|
IH
PACKAGE, insulated brush holder Superseded by part number: 1925379
|
| 21. |
1916324
|
[2] |
VALVE SPRING
|
IH
SPRING, brush Superseded by part number: R16161
|
| 22. |
1878183
|
[2] |
ARM
|
IH
brush Superseded by part number: R15090, 1944373
|
| 23. |
1871693
|
[1] |
|
P
FRAME W/OILER, pin and wick, drive end
|
| 24. |
1880641
|
[1] |
OILER
|
CAS
ASSY, drive end Superseded by part number: 125609
|
| . . |
1823551
|
[1] |
WICK, oiler
|
|
| 25. |
1858603
|
[1] |
BUSHING
|
IH
COLLAR, drive end space Superseded by part number: R16166
|
| 26. |
809945
|
[1] |
BUSHING
|
IH
WASHER, drive end space
|
| 27. |
907503
|
[1] |
BEARING
|
IH
drive end ball Superseded by part number: ST524
|
| 28. |
809961
|
[1] |
FELT
|
IH
WASHER, drive end felt
|
| 29. |
819104
|
[1] |
WASHER
|
IH
PLATE, drive end felt retainer Superseded by part number: R16169
|
| 30. |
1911263
|
[1] |
LARGE PLATE
|
IH
PLATE, drive end retainer Superseded by part number: A52397
|
| 31. |
1912008
|
[1] |
FELT
|
IH
GASKET, drive end and retainer plate Superseded by part number: R16170
|
| 32. |
1911324
|
[1] |
NUT
|
IH
drive end shaft Superseded by part number: 1915172
|
| 34. |
124545
|
[1] |
WOODRUFF KEY,#5, 1/8" x 5/8", HT
|
IH
Superseded by part number: 87034805
|
